T&B® BlueKote® LB18SST Type LB Conduit Body With Cover, Gasket and Screw, 1/2 in Hub, Form 8 Form, 5.8 cu-in Capacity, 316 Stainless Steel, Polished

NOTICE: This item has been flagged as discontinued. Limited stock may be available. Please note that this item is subject to removal from your order if it is unfulfillable.
Short Description

For over 100 years the T&B® brand has been recognized as the leading brand of electrical fittings. industry standards such as Liquidtight® fittings, Erickson® couplings and many others are registered trade marks. The innovation continues with numerous products and features for both ordinary and hazardous locations.

T&B® BlueKote® Conduit Body, Type LB, 1/2 in Hub, 2 Hubs, 5.8 cu-in Capacity, Form 8 Form, Tapered NPT Connection, 316 Stainless Steel, Polished, Gray, 5.07 in L x 2.25 in W x 1.45 in H Dimensions

MFG #: LB18SST

EECO #: TBLB18SST

Brand: Thomas & Betts
UPC #: 786209931160
Discontinued
Attributes
Features
Documents
Product Information
Attributes
Color
Gray
Finish
Polished
UNSPSC
39131708
Used On
IMC/Rigid Conduit
Approval
UL E2969, CSA
Hub Size
1/2
Material
316 Stainless Steel
Form Type
Form 8
Application
Food, Beverage, Pharmaceutical, Petrochemical, Wastewater Treatment, Pulp, Paper Processing and Other Corrosive Environment Applications
Hub Location
90 Degree
Installation
Screw, Threaded
Access Opening
Back
Number of Hubs
2
Connection Type
Tapered NPT
Size
5.7 Inch Lengthx 1.45 Inch Width x 2.25 Inch Height
Type
Type LB
Style
LB
Capacity
5.8
Includes
Cover, Gasket and Screws
Cover Type
316 Stainless Steel
Dimensions
5.07 in L x 2.25 in W x 1.45 in H
Features
  • Marine grade type 316 stainless steel construction in rugged form 8 design
  • NPT tapered threads and integral bushings to protect wire insulation
  • Connect conduit sections
  • Act as pull outlets when conductors are being installed
  • Provide easy access for splices in branch conductors
  • Make 90 deg bends in conduit runs
  • Act as mounting outlets for wiring devices and lighting fixtures
  • Provide access to conductors for maintenance and future system changes
THOBETE64346_1_2
THOBETE68451_E66_E67_E69
T_B_LB27_Technical_Drawing
IDW_DOCUMENT_1520560179515
IDW_DOCUMENT_7e298f9750c69008a85d655bf83a5298b8931d50597b47404dde43505e0d1314
Qty Unit price
Ea
1 $163.29

Slqt
1 $163.29

Stpk
1 $163.29

Unit
1 $163.29
