Sprecher + Schuh RZ7-FSA4UU23 RZ7 Electronic Timing Relay, SPDT Contact, 2 Poles
Sprecher + Schuh RZ7-FSA4UU23 RZ7 Electronic Timing Relay, SPDT Contact, 2 Poles
Sprecher + Schuh RZ7-FSA4UU23 RZ7 Electronic Timing Relay, SPDT Contact, 2 Poles
Sprecher + Schuh RZ7-FSA4UU23 RZ7 Electronic Timing Relay, SPDT Contact, 2 Poles
Sprecher + Schuh RZ7-FSA4UU23 RZ7 Electronic Timing Relay, SPDT Contact, 2 Poles
Sprecher + Schuh RZ7-FSA4UU23 RZ7 Electronic Timing Relay, SPDT Contact, 2 Poles
Share Share Print Print
Sprecher + Schuh

Sprecher + Schuh RZ7-FSA4UU23 RZ7 Electronic Timing Relay, SPDT Contact, 2 Poles

Short Description

24 to 240 VAC at 50/60 Hz, 24 to 48 VDC Coil, 0.05 Sec to 60 Hr, On-Delay, Screw Terminal, AC/DC Operated, Single Function Timing Relay

Sprecher + Schuh, RZ7-FSA4UU23, Timing Relay, Electronic, Series: RZ7, 2 Pole, SPDT Contact Form
MFG #: RZ7-FSA4UU23

EECO #: SSRZ7FSA4UU23

Brand: Sprecher + Schuh
Attributes
Features
Documents
Product Information
Attributes
UNSPSC
39122329
Approval
UL, CE
Coil Voltage
24 to 240 Volt AC at 50/60 Hertz, 24 to 48 Volt DC
Terminal Type
Screw
Mounting
DIN Rail
Contact Configuration
(2) SPDT
Type
Electronic
Series
RZ7
Timing Mode
ON Delay
Timing Range
0.05 Second to 60 Hour
Timing Adjustment Operator Type
Knob
Features
  • Solid State Accuracy and Reliability
  • Eliminates Additional Relays
  • Multiple Functions and Timing Ranges in One Relay
  • Many Safety and Convenience Features
Sprecher_Schuh_RZ7_FSA4UU23_Specification_Sheet
Qty Unit price
Ea
1 $81.30

Slqt
1 $81.30

Stpk
1 $81.30

Unit
1 $81.30
