SolaHD ES5H25S Ventilated Distribution Transformer With WS-15 Optional Weather Shield, 240/480 VAC Primary, 120/240 VAC Secondary, 25 kVA, 60 Hz, 1 Phase
Share Share Print Print
Emerson

SolaHD ES5H25S Ventilated Distribution Transformer With WS-15 Optional Weather Shield, 240/480 VAC Primary, 120/240 VAC Secondary, 25 kVA, 60 Hz, 1 Phase

Short Description

Experience reliable power distribution with the SolaHD ES5H25S Ventilated Distribution Transformer. Designed for efficiency and durability, this transformer features a versatile 240/480 VAC primary and 120/240 VAC secondary, making it ideal for various applications. Enhance its performance further with the optional WS-15 Weather Shield for added protection.Enhanced by AI

SolaHD Distribution Transformer, Ventilated, 240/480 VAC Primary, 120/240 VAC Secondary, 25 kVA, 60 Hz, 1 Phase, 104/52.1/208 A Maximum, 2 Taps, Wall Mount, 428 deg F, NEMA 3R, 302 deg F, 16 in L x 16 in W x 28 in H

MFG #: ES5H25S

EECO #: SOES5H25S

Brand: SolaHD
UPC #: 783472000210
Attributes
Features
Documents
Product Information
Attributes
Phase
1
UNSPSC
39121001
Application
For any situation where the available voltage must be changed to accommodate the voltage required by the specific electrical circuit or connected equipment and outdoor applications
Power Rating
25
Mounting Type
Wall
Enclosure Type
NEMA 3R
Number of Taps
2.0000
Frequency Rating
60
Temperature Rating
302
Type
Ventilated
Warranty
10 years Limited
Dimensions
16 in L x 16 in W x 28 in H
Primary Voltage
240/480
Secondary Voltage
120/240
Features
  • Terminal board connections and spacious wiring compartment
  • Panel enclosure design reduces labor time, wiring diagram on inside front cover
  • High efficiency for low cost operation
  • Copper wound designs
  • Low temperature designs
  • Electrostatic shield for quality power
  • Energy efficient dry-type
  • Fast delivery
  • Compliant with NEMA TP-1 standards, 1 and 3-phase models
  • 302 deg F temperature rise under full load
IDW_DOCUMENT_21cae2fd5ea78f898de07ad333189f6f6ad1386630caabf3caf3233c7f88e152
IDW_DOCUMENT_d0b5103435f780cb0876d505ba635bcfdbc96fb67f0cb619f0fecb35ba3a2c94
Qty Unit price
Ea
1 $4,946.83
