Siemens A6X30090416 RX1000P Industrially Hardened Cyber Security Appliance, 305.8 mm H x 437.4 mm W x 44.5 mm D, RJ-45 Connectivity, 8 Ports

The RX1000P is an industrially hardened, Power over Ethernet (PoE) enabled, cyber security appliance with integrated router, firewall and VPN functionality. The device may be equipped with up to four 10/100BaseTX 802.3af (PoE) compliant Ethernet ports. The RX1000P can be used to establish an electronic security perimeter around critical cyber assets found in control and automation systems, in order to prevent the disruption of operations by accidental or malicious acts. Ideally suited for electric power utilities, the industrial plant floor, and traffic control systems, the RX1000P is designed to protect and secure SCADA system networks connected to the Internet, or within a company's Wide Area Network (WAN) or Local Area Network (LAN). The RX1000P includes security functions such as full IPSec Virtual Private Network (VPN) and firewall capabilities with the capacity to connect hundreds of remote sites over frame relay and PPP. The modular architecture allows the customization of the number and type of Ethernet and WAN ports. Integrated modem, serial interface, and time synchronization options are also available. The RX1000P is hardened to the RuggedRated™ specification which provides a high level of immunity to Electromagnetic Interference (EMI) and heavy electrical surges typical of the harsh environments found in many industrial applications. An operating temperature range of -40 to 85 deg C (-40 to 185 deg F) allows the RX1000P to be placed in almost any location. For applications requiring high availability, the RX1000P provides the option for integrated dual redundant power supplies, each capable of accommodating a wide range of input voltages for worldwide operability. Also unique is the ability to have each power supply fed from different voltage levels and/or sources thereby providing great flexibility in creating high availability systems.
