Siemens AG 6SL30000JE384AA0 Line Harmonic Filter

Name: Siemens AG 6SL30000JE384AA0 Line Harmonic Filter
Brand: Siemens
SKU: SIC6SL30000JE384AA0
Availability: InStock

Short Description

380 to 480 VAC 50/60 Hz 3-Phase, 700 A, 400 to 450 kW, IP21, Line Harmonic Filter

Line Harmonic Filter; Voltage Rating 380 to 480 Volt AC; Current Rating 700 Amp; Frequency Rating 50/60 Hertz; Circuit Type 3-Phase; Enclosure IP21; Size 800 Millimeter Width x 540 Millimeter Depth x 1700 Millimeter Height; Application 400 to 450 Kilowatt Power Module/Chassis Unit of SINAMICS G130 Drive Converter; RoHS Compliant; Finish RAL 7035; Power Loss 4.54 Kilowatt; Applicable Standard IEEE 519-1992

MFG #: 6SL30000JE384AA0

EECO #: SIC6SL30000JE384AA0 SIC6SL30000JE384AA0

Brand: Siemens

UPC #: 662643432268

Attributes

Features

Documents

Product Information

Attributes

UNSPSC

39121000

Application

400 to 450 Kilowatt Power Module/Chassis Unit of SINAMICS G130 Drive Converter

Circuit Type

3-Phase

Current Rating

700 Amp

Voltage Rating

380 to 480 VoltAC

Frequency Rating

50/60 Hertz

Enclosure

IP21

Size

800 Millimeter Width x 540 Millimeter Depth x 1700 Millimeter Height

Features

Harmonics Filters Reduce the Low Frequency Harmonic Effects of Converters to a Level that can Otherwise Only be Achieved Using 12-Pulse Rectifiers
Filters are Supplied as Stand-Alone Components in a Rugged Housing
They are Installed between the Customer's Low Voltage Distribution Panel and the Converter
The Voltage is Disconnected and Fused in the Customer's Low Voltage Switch Gear, as is the Power Supply Cable
The Line Harmonics Filters Have No Fans, this Means that No External Auxiliary Power Supply is Required
Equipped with a Floating Thermostatic Switch, Which can be Monitored Externally, for the Monitoring Thermal Overload
RoHS Compliant
