Siemens 6AG13325HF002AB0 40-Pole Output Optically Isolated Analog Output Module, 8 Outputs, 12 bit Resolution, 0.4/0.5% Voltage, 0.5/0.6% Current Accuracy
Share Share Print Print
Siemens

Siemens 6AG13325HF002AB0 40-Pole Output Optically Isolated Analog Output Module, 8 Outputs, 12 bit Resolution, 0.4/0.5% Voltage, 0.5/0.6% Current Accuracy

Short Description

Enhance your automation systems with the Siemens 6AG13325HF002AB0 Analog Output Module, featuring 8 optically isolated outputs and precise 12-bit resolution. Experience exceptional voltage and current accuracy for reliable performance in diverse applications.Enhanced by AI

Siemens SIPLUS Analog Output Module, 40-Pole Output Optically Isolated, 8 Output, 0.8 ms, 12 bit Resolution, 0.4/0.5% Voltage, 0.5/0.6% Current Accuracy, 24 VDC, 100/340 mA, -25 to 70 deg C, 125 mm H x 40 mm W x 120 mm D

MFG #: 6AG13325HF002AB0

EECO #: SIC6AG13325HF002AB0

Brand: Siemens
Attributes
Features
Documents
Product Information
Attributes
UNSPSC
32151705
Accuracy
0.4/0.5% Voltage, 0.5/0.6% Current
Resolution
12
Voltage Rating
24
Temperature Rating
-25 to 70
Type
40-Pole Output Optically Isolated
Dimensions
125 mm H x 40 mm W x 120 mm D
Amperage Rating
100/340
Number of Outputs
8
Features
  • -25 to 70 deg C with conformal coating based on 6ES7332-5HF00-0AB0
  • Maximum 340 mA from load voltage L+ (without load), maximum 100 mA from backplane bus 5 VDC
  • 40-pin remove/insert active, backplane bus
  • 0.5% voltage, 0.6% current operational error limit at all temperatures, 0.4% voltage, 0.5% current basic error limit at 25 deg C
