Siemens 3RK2400-1DQ00-0AA3 3RK A/B Slave Binary Constant AS-Interface SlimLine Compact Digital I/O Module, 4 Inputs, 4 Outputs
Share Share Print Print
Siemens

Siemens 3RK2400-1DQ00-0AA3 3RK A/B Slave Binary Constant AS-Interface SlimLine Compact Digital I/O Module, 4 Inputs, 4 Outputs

Short Description

Enhance your automation capabilities with the Siemens 3RK2400-1DQ00-0AA3 Compact Digital I/O Module. Featuring 4 inputs and 4 outputs, this reliable A/B Slave Binary Constant module is designed for optimal performance in various environments.Enhanced by AI

Siemens AS-Interface SlimLine Compact Digital I/O Module, A/B Slave Binary Constant, Series: 3RK, 4 Inputs, 4 Outputs, 26.5 to 31.6 VDC, 270 mA, Screw Terminal, -25 to 85 deg C, 152 mm H x 60 mm W x 29 mm D Dimensions

MFG #: 3RK24001DQ000AA3

EECO #: SIC3RK24001DQ000AA3

Brand: Siemens
UPC #: 754554942971
Attributes
Features
Documents
Product Information
Attributes
UNSPSC
39121521
Application
For use in IP65 to K60 control cabinet
Terminal Type
Screw
Voltage Rating
26.5 to 31.6
Number of Inputs
4.0000
Temperature Rating
-25 to 85
Type
A/B Slave Binary Constant
Series
3RK
Dimensions
152 mm H x 60 mm W x 29 mm D
Amperage Rating
270
Number of Outputs
4
Features
  • Simple connection of multiple modules using the device connector
  • Can select between AS-I/Uaux sensor supply
  • Device connector enables easy wiring of multiple modules
