Siemens 3RF2950-0KA16-0KT0 Solid State Power Controller, 50 A, 400 to 600/24 VAC/VDC V Coil
Share Share Print Print
Siemens

Siemens 3RF2950-0KA16-0KT0 Solid State Power Controller, 50 A, 400 to 600/24 VAC/VDC V Coil

Short Description

Elevate your control systems with the Siemens 3RF2950-0KA16-0KT0 Solid State Power Controller. Designed for efficiency and reliability, this 50 A controller operates seamlessly across a range of voltages and features a compact design for easy installation. Enhanced by AI

Siemens Solid State Power Controller, 50 A, 50/60 Hz, 400 to 600/24 VAC/VDC Coil, Clip-On Mount, Screw Terminal, IP20 Enclosure, -25 to 60 deg C, 45 mm W x 69.5 mm D x 111.5 mm H

MFG #: 3RF2950-0KA16-0KT0

EECO #: SIC3RF29500KA160KT0

Brand: Siemens
UPC #: 754554956718
Attributes
Features
Documents
Product Information
Attributes
UNSPSC
39121521
Coil Voltage
400 to 600/24
Mounting Type
Clip-On
Terminal Type
Screw
Enclosure Type
IP20
Frequency Rating
50/60
Temperature Rating
-25 to 60
Dimensions
45 mm W x 69.5 mm D x 111.5 mm H
Amperage Rating
50
Features
  • Model: Siemens 3RF2950-0KA16-0KT0
  • Type: Solid State Power Controller
  • Current Rating: 50 A
  • Frequency: 50/60 Hz
  • Coil Voltage: 400 to 600/24 VAC/VDC
  • Mounting Type: Clip-On Mount
  • Connection Type: Screw Terminal
  • Enclosure Rating: IP20
  • Operating Temperature Range: -25 to 60 °C
  • Dimensions: 45 mm W x 69.5 mm D x 111.5 mm H

Enhanced by AI

Siemens_3RF29500KA160KT0_Specification_Sheet
