Siemens 3RF2190-3AA06 1-Phase Semiconductor Zero Point Switching SIRIUS Solid State Relay, 90 A, 1NO Contact, 15 to 24 VDC V Coil
Share Share Print Print
Siemens

Siemens 3RF2190-3AA06 1-Phase Semiconductor Zero Point Switching SIRIUS Solid State Relay, 90 A, 1NO Contact, 15 to 24 VDC V Coil

Short Description

Elevate your control systems with the Siemens 3RF2190-3AA06 Solid State Relay, featuring 90 A capacity and precise zero point switching. Designed for reliability and efficiency, this 1-Phase relay ensures seamless operation in demanding environments.Enhanced by AI

Siemens SIRIUS Solid State Relay, 1-Phase Semiconductor Zero Point Switching, Series: 3RF, 90 A, 50/60 Hz Frequency, 15 to 24 VDC Coil, 1NO Contact Form, 1 Pole, Clip-On Mounting, Lug Ring Terminal, IP20 Enclosure, -25 to 60 deg C, 85 mm H x 22.5 mm W x 48 mm D Dimensions

MFG #: 3RF2190-3AA06

EECO #: SIC3RF21903AA06

Brand: Siemens
UPC #: 754554861227
Attributes
Features
Documents
Product Information
Attributes
UNSPSC
39121529
Application
For resistive/inductive loads and controlling electrical heat
Coil Voltage
15 to 24
Mounting Type
Clip-On
Terminal Type
Lug Ring
Enclosure Type
IP20
Frequency Rating
50/60
Temperature Rating
-25 to 60
Type
1-Phase Semiconductor Zero Point Switching
Series
3RF
Dimensions
85 mm H x 22.5 mm W x 48 mm D
Amperage Rating
90
Features
  • Flexible for all applications with function modules for retrofitting
  • Possibility of fuseless short-circuit proof design
  • Saves time and costs with fast mounting and commissioning, short start up times and easy wiring
  • Extremely long life, low maintenance, rugged and reliable
  • Space saving and safe thanks to sideby side mounting up to an ambient temperature of 60 deg C
  • Modular design - standardized function modules and heat sinks can be used in conjunction with solid state relays to satisfy individual requirements
