redlion® N-Tron® 112FX4-SC N-Tron® 12-Port Unmanaged Ethernet Switch, (8) 10/100BaseTX RJ-45, (4) 100BaseFX Multi-Mode Fiber Ports With SC Connectors Port, 3.2 Gbps Switching
Share Share Print Print
Red Lion

redlion® N-Tron® 112FX4-SC N-Tron® 12-Port Unmanaged Ethernet Switch, (8) 10/100BaseTX RJ-45, (4) 100BaseFX Multi-Mode Fiber Ports With SC Connectors Port, 3.2 Gbps Switching

Short Description

The N-TRON® 112FX4 unmanaged industrial network switch is designed to meet the most demanding communications requirements while providing high throughput and minimum downtime. The 12-port Ethernet Switch is the perfect low cost solution for mission critical data acquisition, control and Ethernet I/O applications.

redlion® N-Tron® Ethernet Switch, 12-Port Unmanaged, Series: N-Tron®, (8) 10/100BaseTX RJ-45, (4) 100BaseFX Multi-Mode Fiber Ports With SC Connectors Port, 3.2 Gbps Switching, Cat 3/5/MDIX Auto Sensing Cable, SC Duplex Connector, 10 to 49 VDC, 455 mA at 24 VDC Supply, DIN Rail Mounting, 3.09 in Width, 4-1/4 in Height, -40 to 80 deg C, Environmental Conditions: -40 to 85 deg C Storage Temperature, 5 to 95% Humidity
MFG #: 112FX4-SC

EECO #: RN112FX4SC

Brand: Red Lion
Attributes
Features
Documents
Product Information
Attributes
UNSPSC
43222612
Cable Type
Cat 3/5/MDIX Auto Sensing
Application
Industrial and Shipboard Applications
Power Supply
10 to 49 VDC, 455 mA at 24 VDC
Mounting Type
DIN Rail
Connector Type
SC Duplex
Switching Capacity
3.2
Temperature Rating
-40 to 80
Environmental Conditions
-40 to 85 deg C Storage Temperature, 5 to 95% Humidity
Type
12-Port Unmanaged
Width
3.09
Height
4-1/4
Series
N-Tron®
Features
  • Unmanaged plug and play operation
  • RJ-45 port supports full/half duplex operation
  • Auto sensing duplex, speed and MDIX (RJ-45 ports)
  • Full wire speed communication
  • Store and forward technology
  • Compact, space saving package
  • ESD and surge protection on all built-in ports
  • Surge protection diodes on power inputs
  • LED link/activity status indication
  • Hardened metal DIN rail enclosure
redlion_102MCESC15MDR_Manual
redlion_112FX4SC_Line_Drawing
redlion_112FX4SC_Specification_Sheet
