RAB X22-60 X22 Flood Light, LED Lamp, 30, 40, 50, 60 W Fixture, 120, 208, 240, 277 V, Bronze Housing

Short Description

Illuminate your space with the RAB X22-60 X22 Flood Light, featuring versatile wattage options and exceptional LED efficiency. Designed for durability and performance, this fixture offers superior light output and energy savings, making it the perfect choice for any outdoor lighting needs. Enhanced by AI

RAB, X22-60, Flood Light, Series: X22, 120, 208, 240, 277 V, 30, 40, 50, 60 W Fixture, 0.50, 0.29, 0.26, 0.23 A, Mercury/UV-Free Lighting Technology, LED Lamp, 124.7 to 168.6 Lumens/W Light Output, 50000 hr Average Life, 3000, 4000, 5000 K Color Temperature, 81 to 84 CRI, Class 1 Constant Current/0 to 10 VDC Dimming Driver Ballast, Tempered Glass Lens, 4405 to 9353 Lumens, IP65 Enclosure, Knuckle Mounting, Die Cast Aluminum Housing Material, Bronze Housing Finish, 10-5/8 in H x 7-13/16 in W x 7-3/16 in L Dimensions

MFG #: X22-60

EECO #: RABX2260

Brand: RAB
UPC #: 192552032759
Attributes
Features
Documents
Product Information
Attributes
UNSPSC
39111611
Lamp Type
LED
Application
Suitable for wet locations
Mounting Type
Knuckle
Enclosure Type
IP65
Voltage Rating
120, 208, 240, 277
Housing Material
Die-Cast Aluminum
Series
X22
Includes
Integrated photocell
Warranty
5 Years
Lens Type
Tempered Glass
Dimensions
10-5/8 in H x 7-13/16 in W x 7-3/16 in L
Ballast Type
Class 1 Constant Current/0 to 10 VDC Dimming Driver
Housing Finish
Bronze
Amperage Rating
0.50, 0.29, 0.26, 0.23
Features
  • Model: RAB X22-60 Flood Light
  • Power Options: 30, 40, 50, 60 W Fixture
  • Voltage Compatibility: 120, 208, 240, 277 V
  • Light Output: 4405 to 9353 Lumens
  • Luminous Efficacy: 124.7 to 168.6 Lumens/W
  • Average Lifespan: 50,000 hours
  • Color Temperature: 3000, 4000, 5000 K
  • Color Rendering Index (CRI): 81 to 84
  • Dimming Capability: Class 1 Constant Current/0 to 10 VDC Dimming Driver
  • Lighting Technology: Mercury/UV-Free LED
  • Lens Material: Tempered Glass
  • Enclosure Rating: IP65
  • Mounting Type: Knuckle Mounting
  • Housing Material: Die Cast Aluminum
  • Finish: Bronze Housing
  • Dimensions: 10-5/8 in H x 7-13/16 in W x 7-3/16 in L
