RAB T8-13-U6G-840-SD-HYB Type A Plug and Play/B Dimmable Double End Hybrid LED U-Bent Tube, 13 W, 2-Pin G13 Medium LED Lamp, T8 Linear Shape, 2000 Lumens
Share Share Print Print
RAB Lighting

RAB T8-13-U6G-840-SD-HYB Type A Plug and Play/B Dimmable Double End Hybrid LED U-Bent Tube, 13 W, 2-Pin G13 Medium LED Lamp, T8 Linear Shape, 2000 Lumens

Short Description

Illuminate your space with the RAB T8-13-U6G-840-SD-HYB LED U-Bent Tube, delivering 2000 lumens of bright, efficient lighting. This 13W, dimmable, plug-and-play solution is designed for easy installation and optimal performance, making it the perfect choice for any application!Enhanced by AI

RAB LED U-Bent Tube, Type A Plug and Play/B Dimmable Double End Hybrid, T8-13-U6G-840-SD-HYB Designation, 13 W Wattage, 120 to 277 V, LED Lamp, 2-Pin G13 Medium Lamp Base, T8 Linear Shape, 2000 Lumens, 50000 hr Average Life, White, 80 CRI, 4000 K Color Temperature, Frosted Lamp, Instant Start, Electronic Ballast, Enclosed/Open Fixture, 140 deg Beam, 2 ft L x 7-1/16 in W Dimensions

MFG #: T8-13-U6G-840-SD-HYB

EECO #: RABT813U6G840SDHYB

Brand: RAB
UPC #: 019813601687
Attributes
Features
Documents
Product Information
Attributes
Color
White
Shape
T8 Linear
UNSPSC
39101605
Lamp Type
LED
Application
For use in dry or damp locations
Voltage Rating
120 to 277
Type
Type A Plug and Play/B Dimmable Double End Hybrid
Wattage
13
Warranty
5 years
Dimensions
2 ft L x 7-1/16 in W
Ballast Type
Electronic
Fixture Type
Enclosed/Open
Lamp Base Type
2-Pin G13 Medium
Features
  • Direct replacement for fluorescent lamps - F32T8/32W, F32T8/30W, F32T8/28W and F32T8/25W
  • Type A - plug and play compatible with most common commercial instant start T8 electronic ballasts
  • Type B - can be wired directly to line voltage 120 to 277 V and single ended and double ended wiring method
  • Works with both shunted and non-shunted sockets
  • Diffused frosted lens will maintain the same light quality over time
  • Instant-on full brightness
  • Environmentally friendly, no mercury used
