Ocal® OCAL-BLUE® LL18-4X-G Type LL Conduit Body, 1/2 in Hub, Form 8 Form, 4.9 cu-in Capacity, Iron, PVC Coated
Share Share Print Print
ABB

Ocal® OCAL-BLUE® LL18-4X-G Type LL Conduit Body, 1/2 in Hub, Form 8 Form, 4.9 cu-in Capacity, Iron, PVC Coated

Short Description

With outstanding performance in corrosive environments, Ocal® PVC coated conduit and fittings extend the life of your electrical system for many years beyond the lifespan of standard rigid conduit systems. T&B® has removed certain "Only Ocal®" statements from its literature and advertising as part of the settlement of a lawsuit.

Ocal® OCAL-BLUE® Conduit Body, Type LL, 1/2 in Hub, 2 Hubs, 4.9 cu-in Capacity, Form 8 Form, NEMA 4X Enclosure, Thread Connection, Iron, PVC Coated, Dark Gray, 4.94 in L x 1.44 in W x 2.13 in H Dimensions
MFG #: LL18-4X-G

EECO #: OCLL184XG

Brand: Ocal
UPC #: 704508024819
Attributes
Features
Documents
Product Information
Attributes
Color
Dark Gray
Finish
PVC Coated
UNSPSC
39131708
Hub Size
1/2
Material
Iron
Application
For pull outlets for conductors being installed
Number of Hubs
2
Connection Type
Thread
Enclosure
NEMA 4X
Type
Type LL
Capacity
4.9
Dimensions
4.94 in L x 1.44 in W x 2.13 in H
Features
  • UL listed type 4X and NEMA 4X rating for excellent protection in wash down areas, as well as harsh outdoor environments exposed to moisture, rain, ice or snow
  • Double coated superior corrosion protection, bodies and covers coated inside and out with 0.002 in blue urethane, then exterior coated with a minimum of 0.04 in PVC
  • PVC coated cast iron conduit body comes with mated cast iron cover, injection molded with an integral O-ring seal and stainless steel encapsulated screws
  • Provide openings for making splices and taps in conductors
  • Connect conduit sections, make 90 deg bends in conduit runs
  • Provide taps for branch conduit runs
  • Provide for access to conductors for maintenance and future system changes
Ocal_LL37SA_G_Specification_Sheet
