Leviton

125 V 20 A, Leviton Manufacturing Co. Inc. 8300-W Straight Blade Receptacle, White

Short Description

125 V, 20 A, 5-20R, 2-Pole, 3-Wire, White, Thermoplastic Nylon Body/Face, Impact Resistant, Back/Side Wiring, Grounding, Duplex, Straight Blade Receptacle

Straight Blade Receptacle; Type Duplex; Constructional Feature Impact Resistant; Configuration 5-20R; Voltage Rating 125 Volt; Current Rating 20 Amp; Number of Poles 2; Number of Wires 3; Ground Type Grounding; Material Thermoplastic Nylon (Body/Face); Color White; Wiring Back, Side; Grade Extra Heavy Duty Hospital; Approval UL 498, CSA C22.2; Power Rating 1 HP; Material Nickel Plated Brass (Contact/Strap); Temperature Rating -40 to 60 Deg C; Flammability Rating UL 94 V-2; Applicable Standard Federal Specification WC-596, ANSI C73, NEMA WD-6, NOM 057

MFG #: 8300-W

EECO #: LV8300W

UPC #: 078477818633
Attributes
Features
Documents
Product Information
Attributes
Color
White
UNSPSC
39121406
Wiring
Back, Side
Approval
UL 498, CSA C22.2
Material
Thermoplastic Nylon (Body/Face)
Ground Type
Grounding
Current Rating
20 Amp
Voltage Rating
125 Volt
Number Of Poles
2
Number of Wires
3
Type
Duplex, Straight Blade Receptacle
Grade
Extra Heavy Duty Hospital
Configuration
5-20R
Constructional Feature
Impact Resistant
Features
  • Smooth Face does Not Collect Dirt
  • Four Corner Latches Securely Fasten Face
  • Extra Heavy Duty Triple-Wipe, Brass T Contacts for Superior Contact and Conductivity
  • High-Performance Brass #10-32 Terminal Screws to Reduce Conductor Oxidation
  • Back and Side-Wire Ground Termination Brass Strap Version
  • Break-Off Tabs for Easy Two-Circuit Conversion
  • Apron Barrier to Prevent Accidental Contact Between Terminal Screw Heads and Metal Box
  • Exclusive V-Shaped, Serrated Back-Wiring Clamps for Superior Contact
  • Wire Lead Receptacles for Fast and Easy Installation
LEVMFCE11434_1_4
LEVMFCE25495_B15_B16
LEVMFCINST01490
Qty Unit price
Ea
1 $30.09

Slqt
1 $30.09

Stpk
1 $30.09

Unit
1 $30.09
