Leviton® 460C7WLEV LEV Series 3-Phase Dustight North American Rated Watertight Pin and Sleeve Connector, 480 VAC, 60 A, 3 Poles, 4 Wires, Red
Share Share Print Print
Leviton

Leviton® 460C7WLEV LEV Series 3-Phase Dustight North American Rated Watertight Pin and Sleeve Connector, 480 VAC, 60 A, 3 Poles, 4 Wires, Red

Short Description

Ensure reliable and safe connections with the Leviton® 460C7WLEV LEV Series 3-Phase Dusttight Watertight Pin and Sleeve Connector. Rated for 480 VAC and 60 A, this industrial-grade connector is designed to withstand harsh environments while providing exceptional performance.Enhanced by AI

Leviton® Pin and Sleeve Connector, 3-Phase Dustight North American Rated Watertight, Series: LEV Series, 480 VAC, 60 A, 15 hp, 3 Pole, 4 Wires, NEMA 3R/4X/6P/12 NEMA Rating, Industrial Grade, IP66/IP67/IP68/IP69K Enclosure, Hex Socket Screw Terminal, Nylon, Red, 11.01 in L x 4.1 in W Dimensions

MFG #: 460C7WLEV

EECO #: LV460C7WLEV

Brand: Leviton
UPC #: 078477901250
Attributes
Features
Documents
Product Information
Attributes
Color
Red
UNSPSC
39121404
Material
Nylon
Application
Washdown/Outdoor, Food and Beverages Applications
Terminal Type
Hex Socket Screw
Voltage Rating
480
Number of Wires
4
Enclosure
IP66/IP67/IP68/IP69K
Type
3-Phase Dustight North American Rated Watertight
Grade
Industrial
Series
LEV Series
Warranty
5 years Limited
Dimensions
11.01 in L x 4.1 in W
Horsepower
15
Amperage Rating
60
Features
  • LEV series IEC 60309 pin and sleeve devices are designed to simplify your installation, endure the harshest environments and outlast the competition
  • Improved speed of assembly with threaded housings that have less screws for reduced installation time
  • Superior watertight ratings including IP69K for washdown/outdoor applications and industry exclusive IP68 for long term submersion
  • NSF certified sanitary design trusted for use in food and beverage facilities
