480 V 20 A L16-20R, Leviton Manufacturing Co. Inc. 2436 Black & White® Locking Device Flanged Outlet

Short Description

480 V, 3-Phase, 20 A, 3-Pole, 4-Wire, NEMA L16-20R, White, Nylon Body, Grounding, Locking Device Flanged Outlet

Locking Device Flanged Outlet; Type Flanged; Configuration L16-20R; Voltage Rating 480 Volt 3-Phase; Current Rating 20 Amp; Number of Poles 3; Number of Wires 4; Ground Type Grounding; Material Nylon (Face/Body); Color White; Approval UL, CSA C22.2; Wire Size 18 to 10 AWG (Solid/Stranded Copper); Temperature Rating -40 to 60 Deg C; Application Industrial; Applicable Standard WD-6, ANSI C73, Federal Specification WC-596

MFG #: 2436

EECO #: LV2436

UPC #: 078477806340
Attributes
Features
Documents
Product Information
Attributes
Color
White
UNSPSC
39121400
Approval
UL, CSA C22.2
Material
Nylon (Face/Body)
Ground Type
Grounding
Current Rating
20 Amp
Voltage Rating
480 Volt 3-Phase
Number Of Poles
3
Number of Wires
4
Type
Flanged Outlet
Configuration
L16-20R
Features
  • Rugged Nylon Flange Fits Flush and Won't Crack in High Abuse Applications
  • Individual Deep Funneled Chamfered Wire Wells Guide Each Wire into Rectangular Chambers
  • Wire Clamps Bundle Stranded Wire without Cutting Wire Strands
