Wiring Device-Kellems RCD108LA Decorator 2-Position Standard Switch And Receptacle, Electrical Ratings: 15 A at 120/125 VAC, 1 Poles, 3 Wires, 14 to 12 AWG Wire, Snap Switch Reset
Share Share Print Print
Hubbell

Wiring Device-Kellems RCD108LA Decorator 2-Position Standard Switch And Receptacle, Electrical Ratings: 15 A at 120/125 VAC, 1 Poles, 3 Wires, 14 to 12 AWG Wire, Snap Switch Reset

NOTICE: This item has been flagged as discontinued. Limited stock may be available. Please note that this item is subject to removal from your order if it is unfulfillable.
Short Description

Upgrade your home’s electrical functionality with the Wiring Device-Kellems RCD108LA Decorator Switch and Receptacle. Designed for reliability and convenience, this combination device features a sleek light almond finish, 15 A electrical rating, and a snap switch reset for easy operation. Perfect for residential use, it accommodates 14 to 12 AWG wire and ensures a secure fit with its threaded mounting and self-grounding design. Enhance your space with this essential electrical solution!Enhanced by AI

Wiring Device-Kellems, RCD108LA, Switch And Receptacle, 2-Position Standard, Series: Decorator, 15 A at 120/125 VAC Electrical Rating, 1 Pole, 3 Wires, 14 to 12 AWG Wire, NEMA 5-15R Enclosure, Threaded Mounting, Self-Grounding Grounding Style, Snap Switch Reset, Residential Grade, Side Wire Terminal, 1500 VAC Dielectric Strength, Light Almond, 1.32 in W x 1.09 in D x 4.2 in H Dimensions

MFG #: RCD108LA

EECO #: HURCD108LA

Brand: Wiring Device-Kellems
UPC #: 883778119132
Discontinued
Attributes
Features
Documents
Product Information
Attributes
Color
Light Almond
UNSPSC
39122231
Wire Size
14 to 12
Reset Type
Snap Switch
Application
Residential Applications
Terminal Type
Side Wire
Number of Wires
3
Mounting
Threaded
Enclosure
NEMA 5-15R
Type
2-Position Standard
Grade
Residential
Series
Decorator
Dimensions
1.32 in W x 1.09 in D x 4.2 in H
Grounding Style
Self-Grounding
Dielectric Strength
1500
Features
  • Smooth, quiet rocker
  • Low profile, <1 in D
  • Self-grounding feature is standard
  • -20 to 60 deg C operating temperature without impact
  • Snap switch action
  • Two position contact configuration
  • 30000 minimum operating cycles
  • 14 to 12 AWG solid and stranded copper wire only back and side wire, 14 AWG solid copper wire only push wire mechanical terminal accommodation
  • 2-pole receptacle
  • Brass rocker contacts and terminal, zinc plated steel bridge, drive screw and mounting screw, plastic base, cover, rocker button, spring housing and washers
  • Stainless steel grounding spring, silver switch contact, steel spring
  • 15 A at 120 VAC switch, 15 A at 125 VAC receptacle
  • 1-pole switch, 2-pole receptacle
  • (1) 1-pole rocker, (1) single receptacle
