Wiring Device-Kellems RC308 2-Position 3-Way Snap Action Toggle Self-Grounding Combination Switch and Receptacle, Electrical Ratings: 15 A at 120/125 VAC, 1 Poles, 3 Wires, Snap Switch Reset
Share Share Print Print
Hubbell

Wiring Device-Kellems RC308 2-Position 3-Way Snap Action Toggle Self-Grounding Combination Switch and Receptacle, Electrical Ratings: 15 A at 120/125 VAC, 1 Poles, 3 Wires, Snap Switch Reset

NOTICE: This item has been flagged as discontinued. Limited stock may be available. Please note that this item is subject to removal from your order if it is unfulfillable.
Short Description

Upgrade your electrical setup with the Wiring Device-Kellems RC308 Combination Switch and Receptacle. Featuring a 2-Position 3-Way Snap Action Toggle, this self-grounding device ensures safety and reliability with a 15 A rating at 120/125 VAC. Perfect for residential use, its compact design and easy installation make it an essential addition to any home.Enhanced by AI

Wiring Device-Kellems, RC308, Combination Switch and Receptacle, 2-Position 3-Way Snap Action Toggle Self-Grounding, 15 A at 120/125 VAC Electrical Rating, 1 Pole, 3 Wires, NEMA 5-15R Enclosure, Threaded Mounting, Self-Grounding Grounding Style, Snap Switch Reset, Residential Grade, Side Wire Terminal, Brown, 1.32 in W x 0.97 in D x 4.2 in H Dimensions

MFG #: RC308

EECO #: HURC308

Brand: Wiring Device-Kellems
UPC #: 883778109836
Discontinued
Attributes
Features
Documents
Product Information
Attributes
Color
Brown
UNSPSC
39122226
Reset Type
Snap Switch
Application
Residential Applications
Terminal Type
Side Wire
Number of Wires
3
Mounting
Threaded
Enclosure
NEMA 5-15R
Type
2-Position 3-Way Snap Action Toggle Self-Grounding
Grade
Residential
Dimensions
1.32 in W x 0.97 in D x 4.2 in H
Grounding Style
Self-Grounding
Features
  • Self-grounding feature is standard
  • Combination devices provide compact switches in a 1-gang opening
  • Smooth toggle action
  • Multiple drive Slot/Phillips®/Robertson head screws
  • Combination of (1) 3-way switch, (1) 2-pole receptacle
  • Mini-toggles provide for multiple switches in a compact single gang
  • Maximize control while maintaining function and appearance
  • Low profile, less than 1 in allows for maximum wiring room in the box
  • Elongated strap with continuous plaster ears to fit device flush to the wall surface
  • Multiple drive head screws (slotted/Phillips/Robertson)
  • Hi-visibility yellow base for easy installation in low light working conditions
  • -20 to 60 deg C operating temperature
  • Snap switch action
  • 2-position contact configuration
  • Indoor dry unless protected by additional means
  • Screw mount
  • 30000 minimum operating cycle
