Wiring Device-Kellems RC109W Standard Sized Combination Toggle Switch, 120 VAC, 15 A, 1800 W

Short Description

Upgrade your electrical control with the Wiring Device-Kellems RC109W Combination Toggle Switch. Designed for efficiency and reliability, this standard-sized switch features an amber neon pilot lamp and a robust 15 A capacity, perfect for a range of applications. Experience superior performance and easy installation with its threaded mounting and side wire terminal.Enhanced by AI

Wiring Device-Kellems, RC109W, Combination Toggle Switch, Standard Sized, 120 VAC, 15 A, 1800 W Wattage, 1 Pole, Amber Neon Pilot Lamp, 2-Position Contact Configuration, 15 A Contact, Snap Action, Threaded Mounting, Side Wire Terminal, -20 to 60 deg C, Composite, White, 1.32 in W x 1.53 in D x 4.2 in H Dimensions

MFG #: RC109W

EECO #: HURC109W

Brand: Wiring Device-Kellems
UPC #: 883778110030
Attributes
Features
Documents
Product Information
Attributes
Color
White
UNSPSC
39122231
Material
Composite
Lamp Type
Amber Neon Pilot
Application
Circuit Control and Indication Residential Applications
Terminal Type
Side Wire
Contact Rating
15
Voltage Rating
120
Mounting
Threaded
Temperature Rating
-20 to 60
Contact Configuration
2-Position
Type
Standard Sized
Wattage
1800
Dimensions
1.32 in W x 1.53 in D x 4.2 in H
Amperage Rating
15
Features
  • Quiet snap action mechanism
  • Self-grounding staple is standard
  • Elongated strap with continuous plaster ears
  • Low profile, <1 in D
  • Self-grounding feature is standard
  • Mini-toggles provide for multiple switches in a compact single gang
  • Maximize control while maintaining function and appearance
  • Combination devices provide compact switches in a 1-gang opening
  • Multiple drive slot/Phillips/Robertson head screw
  • Hi-visibility yellow base for easy installation
  • Zinc plated steel bridge, center fastener and mounting screws
  • Brass rocker contacts and terminal
  • Plastic base, cover, toggle, spring housing and washers and steel spring
  • Traditional switch and amber pilot light
  • Combination of (1) 1-pole toggle, (1) pilot light
