Wiring Device-Kellems Twist-Lock® Hubbell-Pro™ Select Spec™ L715C Heavy Duty Isolated Grounding Standard Sized Cord Mount Female Connector, 277 VAC, 15 A, 2 Poles, 3 Wires, Black/White
Wiring Device-Kellems Twist-Lock® Hubbell-Pro™ Select Spec™ L715C Heavy Duty Isolated Grounding Standard Sized Cord Mount Female Connector, 277 VAC, 15 A, 2 Poles, 3 Wires, Black/White
Wiring Device-Kellems Twist-Lock® Hubbell-Pro™ Select Spec™ L715C Heavy Duty Isolated Grounding Standard Sized Cord Mount Female Connector, 277 VAC, 15 A, 2 Poles, 3 Wires, Black/White
Wiring Device-Kellems Twist-Lock® Hubbell-Pro™ Select Spec™ L715C Heavy Duty Isolated Grounding Standard Sized Cord Mount Female Connector, 277 VAC, 15 A, 2 Poles, 3 Wires, Black/White
Share Share Print Print
Hubbell

Wiring Device-Kellems Twist-Lock® Hubbell-Pro™ Select Spec™ L715C Heavy Duty Isolated Grounding Standard Sized Cord Mount Female Connector, 277 VAC, 15 A, 2 Poles, 3 Wires, Black/White

Short Description

Experience reliable performance with the Wiring Device-Kellems Twist-Lock® Hubbell-Pro™ Select Spec™ L715C Heavy Duty Isolated Grounding Connector. Designed for commercial and industrial use, this durable connector ensures safe connections in demanding environments.Enhanced by AI

Wiring Device-Kellems Twist-Lock® Hubbell-Pro™ Select Spec™ Female Connector, Heavy Duty Isolated Grounding Standard Sized Cord Mount, 277 VAC, 15 A, 2 Pole, 3 Wires, L7-15R/WD1/WD5 NEMA Rating, Commercial/Industrial Grade, -40 to 75 deg C, Screw Terminal, Composite, Black/White

MFG #: L715C

EECO #: HUL715C

Brand: Wiring Device-Kellems
UPC #: 783585835730
Attributes
Features
Documents
Product Information
Attributes
Color
Black/White
UNSPSC
39121421
Material
Composite
Application
Indoor Applications
Terminal Type
Screw
Voltage Rating
277
Number of Wires
3
Temperature Rating
-40 to 75
Type
Heavy Duty Isolated Grounding Standard Sized Cord Mount
Grade
Commercial/Industrial
Amperage Rating
15
Features
  • Hubbell-Pro locking devices provide a safe disconnect solution between an equipment load and a power source
  • These devices incorporate a locking interface that is engaged and disengaged simply by rotating the device assuring a safe and reliable electrical connection
  • Maximum 30 deg C temperature rise at full rated current after 50 cycles overload at 150% rated current for either AC or DC applications per
  • Certified for current interrupting at full rated current
  • Withstands 3500 VAC per UL498 dielectric voltage
  • Minimum 4.8 times rated current for 100 cycles overload
  • 18 to 8 AWG flexible cord terminal accommodation
  • 600 VAC/250 VDC maximum working voltage
  • Ratings and NEMA identification are permanently marked on device
  • Nylon construction, visible NEMA ratings, captive assembly screws
  • Impact modified nylon blade/contact holder
  • High performance copper alloy contacts/blade
