Wiring Device-Kellems HBL99CM65C 1-Phase Grounding Male Locking Plug, 125/250 VAC, 20 A, 3 Poles, 3 Wires, Yellow
Share Share Print Print
Hubbell

Wiring Device-Kellems HBL99CM65C 1-Phase Grounding Male Locking Plug, 125/250 VAC, 20 A, 3 Poles, 3 Wires, Yellow

Short Description

Ensure reliable power connections with the Wiring Device-Kellems HBL99CM65C Locking Plug. Designed for durability and safety, this 1-Phase Grounding Male Plug is perfect for marine applications, offering robust performance in challenging environments.Enhanced by AI

Wiring Device-Kellems, HBL99CM65C, Locking Plug, 1-Phase Grounding Male, 125/250 VAC, 20 A, 3 Pole, 3 Wires, Marine Grade, IP20 Enclosure, 0.36 to 0.93 in Diameter Cord, -40 to 75 deg C, Screw Terminal, Nylon, Yellow, 2.26 x 2.26 x 2.75 in Dimensions

MFG #: HBL99CM65C

EECO #: HUHBL99CM65C

Brand: Wiring Device-Kellems
UPC #: 783585037646
Attributes
Features
Documents
Product Information
Attributes
Color
Yellow
UNSPSC
39121403
Material
Nylon
Terminal Type
Screw
Voltage Rating
125/250
Number of Wires
3
Enclosure
IP20
Temperature Rating
-40 to 75
Type
1-Phase Grounding Male
Grade
Marine
Dimensions
2.26 x 2.26 x 2.75
Amperage Rating
20
Features
  • Ribbed nylon housing provides a secure grip and impact and chemical resistance
  • Stainless steel, multi-drive cord clamp screw body holding screw
  • Molded-in or stamped-on ratings
  • 2000 VAC minimum dielectric withstand voltage
  • 12 AWG terminal accommodation
  • Nickel plated blades and stainless steel screws provide maximum corrosion resistance
  • Superior cord grip design protects terminations from excess strain
  • Integral dust shield protects wiring chamber from dust or contaminants
  • Non-NEMA rating
  • Natural white nylon blade holder, nylon cord clamp
  • Clear polycarbonate terminal retainer
  • Brass blade
  • 0.08 in brass nickel plated terminal clamp
  • #10-32 bronze (white finish on neutral screw when used) multi-drive terminal screw
