125 VAC 15 A 5-15R, Hubbell Incorporated HBL5969VY Valise® Straight Blade Connector, Yellow
125 VAC 15 A 5-15R, Hubbell Incorporated HBL5969VY Valise® Straight Blade Connector, Yellow
125 VAC 15 A 5-15R, Hubbell Incorporated HBL5969VY Valise® Straight Blade Connector, Yellow
125 VAC 15 A 5-15R, Hubbell Incorporated HBL5969VY Valise® Straight Blade Connector, Yellow
Share Share Print Print
Hubbell

125 VAC 15 A 5-15R, Hubbell Incorporated HBL5969VY Valise® Straight Blade Connector, Yellow

Short Description

125 VAC, 15 A, 5-15R, 2-Pole, 3-Wire, Yellow, Nylon, Straight Blade Connector

Straight Blade Connector; Configuration 5-15R; Voltage Rating 125 Volt AC; Current Rating 15 Amp; Number of Poles 2; Number of Wires 3; Ground Type Grounding; Color Yellow; Cord Size 0.22 to 0.66 Inch; Material Nylon; Approval UL 498, CSA C22.2; Enclosure Rating IP20; Temperature Rating -40 to 75 Deg C; Applicable Standard NEMA WD 6

MFG #: HBL5969VY

EECO #: HUHBL5969VY

Brand: Wiring Device-Kellems
UPC #: 783585013107
Attributes
Features
Documents
Product Information
Attributes
Color
Yellow
UNSPSC
39121400
Approval
UL 498, CSA C22.2
Material
Nylon
Ground Type
Grounding
Current Rating
15 amp
Voltage Rating
125 Volt AC
Number Of Poles
2
Number of Wires
3
Type
Straight Blade Connector
Cord Size
0.22 to 0.66 Inch
Configuration
5-15R
Features
  • Hinged 1-Piece Body Design for Easy Assembly
  • Powerful, Offsetting Cord Grips Clamp on Individual Conductors
  • Assembly Screws are Captive and will not Fall Out While Wiring
HUBKELE08364_1
HUBKELE15735_A34_A62
HUBKELINST00065
Qty Unit price
Ea
1 $17.50

Slqt
1 $17.50

Stpk
1 $175.00

Unit
1 $17.50
