125 VAC 20 A 5-20P, Hubbell Incorporated HBL5366CA Insulgrip® Straight Blade Plug, Yellow/Black/White
125 VAC 20 A 5-20P, Hubbell Incorporated HBL5366CA Insulgrip® Straight Blade Plug, Yellow/Black/White
125 VAC 20 A 5-20P, Hubbell Incorporated HBL5366CA Insulgrip® Straight Blade Plug, Yellow/Black/White
125 VAC 20 A 5-20P, Hubbell Incorporated HBL5366CA Insulgrip® Straight Blade Plug, Yellow/Black/White
Share Share Print Print
Hubbell

125 VAC 20 A 5-20P, Hubbell Incorporated HBL5366CA Insulgrip® Straight Blade Plug, Yellow/Black/White

Short Description

125 VAC, 20 A, 5-20P, 2-Pole, 3-Wire, Yellow, Black/White, Grounding, Angled, 8-Position, Straight Blade Plug

Straight Blade Plug; Type Angled, 8-Position; Configuration 5-20P; Voltage Rating 125 Volt AC; Current Rating 20 Amp; Number of Poles 2; Number of Wires 3; Ground Type Grounding; Cord Size 0.325 to 0.655 Inch; Material Nylon; Color Black/White; Approval UL 498, CSA C22.2; Blade Holder Material Nylon; Terminal Retainer Material Clear Polycarbonate; Terminal Clamp Material Nickel Plated Steel; Terminal Screw #8-32 TPI Brass; Enclosure Rating IP20; Temperature Rating -40 to 75 Deg C; Applicable Standard Federal Specification W-C596G, NEMA WD-6

MFG #: HBL5366CA

EECO #: HUHBL5366CA

Brand: Wiring Device-Kellems
UPC #: 783585174006
Attributes
Features
Documents
Product Information
Attributes
Color
Black/White
UNSPSC
39121402
Approval
UL 498, CSA C22.2
Material
Nylon
Ground Type
Grounding
Current Rating
20 Amp
Voltage Rating
125 Volt AC
Number Of Poles
2
Number of Wires
3
Type
Angled, 8-Position Plug
Cord Size
0.325 to 0.655 Inch
Configuration
5-20P
Features
  • 8-Position Angled Plug
  • Low Profile
  • Roomy Wiring Chamber Provides Ample Space for Wiring Each Insulgrip Device is Manufactured with Roomy, Separate Wiring Chambers to Insulate Conductors and an Individually Molded Face to Keep Out Dust and Debris that can Cause Contamination Over Time
  • The Insulgrip's Cord Gripping Design Clamps Conductors, Not Just the Cable Jacket, Making it the Industry's Most Powerful Cord Grip with Superior Strain Relief
  • Powerful Cord Grips Clamp on Individual Conductors and Outer Cord Jacket to Prevent Strain on Terminations
  • Individual Wiring Terminals are Completely Enclosed in their Own Separate Chambers
  • Multiple Drive Screw Heads Provide Screwdriver Versatility
  • Pocketed Recess for Cord Grip Screws Deters Slippage of the Screwdriver
HUBKELE07807_1
HUBKELE15735_A33
HUBKELINST00064
Qty Unit price
Ea
1 $22.60

Slqt
1 $22.60

Stpk
1 $22.60

Unit
1 $22.60
