250 VAC 20 A L15-20R, Hubbell Incorporated HBL27W75 Twist-Lock® Locking Device Connector
250 VAC 20 A L15-20R, Hubbell Incorporated HBL27W75 Twist-Lock® Locking Device Connector
250 VAC 20 A L15-20R, Hubbell Incorporated HBL27W75 Twist-Lock® Locking Device Connector
250 VAC 20 A L15-20R, Hubbell Incorporated HBL27W75 Twist-Lock® Locking Device Connector
Share Share Print Print
Hubbell

250 VAC 20 A L15-20R, Hubbell Incorporated HBL27W75 Twist-Lock® Locking Device Connector

Short Description

250 VAC, 3-Phase, 20 A, 3-Pole, 4-Wire, Yellow, Thermoplastic Elastomer, NEMA L15-20R, Polarized, Locking Device Connector

Locking Device Connector; Type Polarized; Constructional Feature Corrosion Resistant, Water Tight; Configuration L15-20R; Voltage Rating 250 Volt AC 3-Phase; Current Rating 20 Amp; Number of Poles 3; Number of Wires 4; Material Thermoplastic Elastomer; Color Yellow; Cord Size 0.375 to 0.875 Inch; Approval UL 498, CSA C22.2; Enclosure Rating 4/4X/12/6/6P; Contact Material Nickel Plated Brass; Temperature Rating -40 to 60 Deg C; Applicable Standard WD-1/6, ANSI

MFG #: HBL27W75

EECO #: HUHBL27W75

Brand: Wiring Device-Kellems
UPC #: 783585131801
Attributes
Features
Documents
Product Information
Attributes
Color
Yellow
UNSPSC
39121400
Approval
UL 498, CSA C22.2
Material
Thermoplastic Elastomer
Current Rating
20 Amp
Voltage Rating
250 Volt AC 3-Phase
Number Of Poles
3
Number of Wires
4
Type
Polarized, Connector
Cord Size
0.375 to 0.875 Inch
Configuration
L15-20R
Constructional Feature
Corrosion Resistant, Water Tight
Features
  • Smooth Body Design Minimizes Collection Points Simplifying the Wash Down Process
  • Strain Relief Nut Always Seals on the Body, Minimizing Debris Collection
  • Stainless Steel Hardware and Corrosion Resistant Connection Points
HUBKELE08163_1
HUBKELE15751_C7
HUBKELINST00551
