250 VAC 30 A L6-30P, Hubbell Incorporated HBL2625SW Twist-Lock®, Safety-Shroud® Locking Device Flanged Inlet
250 VAC 30 A L6-30P, Hubbell Incorporated HBL2625SW Twist-Lock®, Safety-Shroud® Locking Device Flanged Inlet
250 VAC 30 A L6-30P, Hubbell Incorporated HBL2625SW Twist-Lock®, Safety-Shroud® Locking Device Flanged Inlet
250 VAC 30 A L6-30P, Hubbell Incorporated HBL2625SW Twist-Lock®, Safety-Shroud® Locking Device Flanged Inlet
Share Share Print Print
Hubbell

250 VAC 30 A L6-30P, Hubbell Incorporated HBL2625SW Twist-Lock®, Safety-Shroud® Locking Device Flanged Inlet

Short Description

250 VAC, 30 A, 2-Pole, 3-Wire, L6-30P, Grounding, Gray, PBT, Polarized, Locking Device Flanged Inlet

Locking Device Flanged Inlet; Type Polarized; Constructional Feature Impact/Moisture Resistant, Water Tight; Configuration L6-30P; Voltage Rating 250 Volt AC; Current Rating 30 Amp; Number of Poles 2; Number of Wires 3; Ground Type Grounding; Material PBT; Color Gray; Approval UL 498, CSA C22.2; Overall Dimension 3.75 Inch Width x 2.28 Inch Depth x 3.75 Inch Height; Wire Size 16 to 8 AWG; Enclosure Rating 4/4X/12/IP66; Terminal Type Screw; Blade Material Brass; Temperature Rating -40 to 75 Deg C; Applicable Standard Federal Specification WC-596

MFG #: HBL2625SW

EECO #: HUHBL2625SW

Brand: Wiring Device-Kellems
UPC #: 783585231723
Attributes
Features
Documents
Product Information
Attributes
Color
Gray
UNSPSC
39121400
Approval
UL 498, CSA C22.2
Material
PBT
Ground Type
Grounding
Current Rating
30 Amp
Voltage Rating
250 Volt AC
Number Of Poles
2
Number of Wires
3
Type
Polarized Flanged Inlet
Configuration
L6-30P
Constructional Feature
Impact/Moisture Resistant, Water Tight
Features
  • UL Type 4X Environmental Seal Protects Connection While in Use
  • One-Piece, Engineered Thermoplastic Housing is Impact Resistant for Heavy-Duty Industrial Environments
  • Alignment Arrows and Lock and Unlock Symbols Provide a Visual Indication that Devices are Properly Connected
  • Closure Cap is Included for Environmental Seal When Device is Not in Use
  • Catalog Number and Color- Coded Voltage Rating are Easily Visible Even When in Use
