250 VAC 30 A L6-30R, Hubbell Incorporated HBL2623BK Twist-Lock®, Insulgrip® Locking Device Connector

Short Description

250 VAC, 30 A, 16 to 8 AWG, 2-Pole, 3-Wire, Black, Nylon, NEMA L6-30R, Polarized, Locking Device Connector

Locking Device Connector; Type Polarized; Constructional Feature Chemical Resistant; Configuration L6-30R; Voltage Rating 250 Volt AC; Current Rating 30 Amp; Number of Poles 2; Number of Wires 3; Ground Type Grounding; Material Nylon; Color Black; Cord Size 0.36 to 0.93 Inch; Approval UL 498, CSA C22.2; Wire Size 16 to 8 AWG (Stranded Copper); Enclosure Rating IP20; Contact Material Brass; Temperature Rating -40 to 75 Deg C; Applicable Standard Federal Specification WC-596

MFG #: HBL2623BK

EECO #: HUHBL2623BK

Brand: Wiring Device-Kellems
UPC #: 783585172255
Attributes
Features
Documents
Product Information
Attributes
Color
Black
UNSPSC
39121400
Approval
UL 498, CSA C22.2
Material
Nylon
Ground Type
Grounding
Current Rating
30 Amp
Voltage Rating
250 Volt AC
Number Of Poles
2
Number of Wires
3
Type
Polarized, Connector
Cord Size
0.36 to 0.93 Inch
Configuration
L6-30R
Constructional Feature
Chemical Resistant
Features
  • Superior Cord Grip Design Protects Terminations from Excess Strain
  • Clear, Funnel Shaped Wire Entry for Ease of Termination
  • Integral Dust Shield Protects Wiring Chamber from Dust or Contaminants
HUBKELE10683_1
HUBKELE15739_B14_B29
HUBKELINST00604
