Print480 VAC 20 A L16-20R, Hubbell Incorporated HBL24CM33 Twist-Lock®, Insulgrip® Locking Device Connector
Short Description
480 VAC, 3-Phase, 20 A, 16 to 8 AWG, 3-Pole, 4-Wire, Yellow, Nylon, NEMA L16-20R, Polarized, Locking Device Connector
Locking Device Connector; Type Polarized; Constructional Feature Impact/Chemical/Corrosion Resistant; Configuration L16-20R; Voltage Rating 480 Volt AC 3-Phase; Current Rating 20 Amp; Number of Poles 3; Number of Wires 4; Ground Type Grounding; Material Nylon; Color Yellow; Cord Size 0.35 to 1.15 Inch; Approval UL 498, CSA C22.2; Wire Size 16 to 8 AWG (Stranded Copper); Enclosure Rating IP20; Contact Material Brass; Temperature Rating -40 to 75 Deg C; Applicable Standard Federal Specification WC-596
MFG #:
HBL24CM33
EECO #: HUHBL24CM33
Brand:
Wiring Device-Kellems
UPC #:
783585038520
| Qty | Unit price |
|---|---|
| Ea | |
| 1 | $48.90 |
|
Slqt |
|
| 1 | $48.90 |
|
Stpk |
|
| 1 | $48.90 |
|
Unit |
|
| 1 | $48.90 |
