250 VAC 20 A L6-20R, Hubbell Incorporated HBL2323 Twist-Lock®, Insulgrip® Locking Device Connector
250 VAC 20 A L6-20R, Hubbell Incorporated HBL2323 Twist-Lock®, Insulgrip® Locking Device Connector
250 VAC 20 A L6-20R, Hubbell Incorporated HBL2323 Twist-Lock®, Insulgrip® Locking Device Connector
250 VAC 20 A L6-20R, Hubbell Incorporated HBL2323 Twist-Lock®, Insulgrip® Locking Device Connector
Share Share Print Print
Hubbell

250 VAC 20 A L6-20R, Hubbell Incorporated HBL2323 Twist-Lock®, Insulgrip® Locking Device Connector

Short Description

250 VAC, 20 A, 16 to 8 AWG, 2-Pole, 3-Wire, Black/White, Nylon, NEMA L6-20R, Polarized, Locking Device Connector

Locking Device Connector; Type Polarized; Constructional Feature Impact/Chemical Resistant; Configuration L6-20R; Voltage Rating 250 Volt AC; Current Rating 20 Amp; Number of Poles 2; Number of Wires 3; Ground Type Grounding; Material Nylon; Color Black/White; Cord Size 0.36 to 0.93 Inch; Approval UL 498, CSA C22.2; Wire Size 16 to 8 AWG (Stranded Copper); Enclosure Rating IP20; Contact Material Brass; Temperature Rating -40 to 75 Deg C; Applicable Standard Federal Specification WC-596

MFG #: HBL2323

EECO #: HUHBL2323

Brand: Wiring Device-Kellems
UPC #: 783585037844
Attributes
Features
Documents
Product Information
Attributes
Color
Black/White
UNSPSC
39121400
Approval
UL 498, CSA C22.2
Material
Nylon
Ground Type
Grounding
Current Rating
20 Amp
Voltage Rating
250 Volt AC
Number Of Poles
2
Number of Wires
3
Type
Polarized, Connector
Cord Size
0.36 to 0.93 Inch
Configuration
L6-20R
Constructional Feature
Impact/Chemical Resistant
Features
  • Ribbed Nylon Housing Provides a Secure Grip and Impact and Chemical Resistance
  • Superior Cord Grip Design Protects Terminations from Excess Strain
  • Clear, Funnel Shaped Wire Entry for Ease of Termination
  • Integral Dust Shield Protects Wiring Chamber from Dust or Contaminants
HUBKELE04268_1
HUBKELE15739_B14_B21
HUBKELINST00604
Qty Unit price
Ea
1 $28.60

Slqt
1 $28.60

Stpk
1 $28.60

Unit
1 $28.60
