Wiring Device-Kellems FRFBRS2A Standard Fire-Rated Poke-Through Flush Service Fitting, 7 in Dia, Composite
Share Share Print Print
Hubbell

Wiring Device-Kellems FRFBRS2A Standard Fire-Rated Poke-Through Flush Service Fitting, 7 in Dia, Composite

Short Description

Prewired Hubbell® HBL5352 series (20 A) specification grade receptacle and two low voltage knockouts. Equipped with a cast aluminum carpet flange and a thermoplastic (ABS) duplex flap cover.

Wiring Device-Kellems, FRFBRS2A, Standard Fire-Rated Poke-Through Flush Service Fitting, 3 Outlets, 2 Knockouts, 1/2 in Knockout, 7 in Diameter, 0.49 in Thickness, Round Shape, Hole Mounting, Composite, Brass Plated, Yellow
MFG #: FRFBRS2A

EECO #: HUFRFBRS2A

Brand: Wiring Device-Kellems
UPC #: 783585396149
Attributes
Features
Documents
Product Information
Attributes
Color
Yellow
Shape
Round
Finish
Brass Plated
UNSPSC
39121328
Material
Composite
Application
For fire rated poke-through and in-floor delivery systems
Knockout Size
1/2
Mounting Type
Hole
Number of Outlets
3.0000
Number of Knockouts
2.0000
Type
1-Phase Corrosion Resistant Grounding Male Standard Cord Mount
Diameter
7
Includes
Pre-Wired 20 A Duplex Receptacle, Solid Brass Flip Lid Cover With (2) 1/2 in Low Voltage Feed-through Holes, Solid Brass Flange
Thickness
0.49
Features
  • Equipped with a cast aluminum carpet flange and a thermoplastic (ABS) duplex flap cover
  • 2-1/4 in (over metal deck) to 7 in-floor thickness range
  • Minimum of 2 ft on centers and not more than one unit per 65 sq-ft floor area in each span spacing
  • Painted cast aluminum/solid brass, brushed and lacquered carpet flange material
  • For use in 1, 1-1/2, 2, 3 or 4 hr rated unprotected reinforced concrete floors or in 1, 2 or 3 hr rated floors employing steel floor units and concrete topping (D900 series design)
  • Fabricated construction
  • 3 in core hole in concrete floor
