90.06 x 72.06 x 24.06, Hoffman A907224FSDADG Freestanding Enclosure, NEMA 12/IP55, 12 Gauge Steel, 2-Door
90.06 x 72.06 x 24.06, Hoffman A907224FSDADG Freestanding Enclosure, NEMA 12/IP55, 12 Gauge Steel, 2-Door
90.06 x 72.06 x 24.06, Hoffman A907224FSDADG Freestanding Enclosure, NEMA 12/IP55, 12 Gauge Steel, 2-Door
90.06 x 72.06 x 24.06, Hoffman A907224FSDADG Freestanding Enclosure, NEMA 12/IP55, 12 Gauge Steel, 2-Door
Share Share Print Print
nVent

90.06 x 72.06 x 24.06, Hoffman A907224FSDADG Freestanding Enclosure, NEMA 12/IP55, 12 Gauge Steel, 2-Door

Short Description

90.06" x 72.06" x 24.06", NEMA 12, IP55, ANSI 61 Gray, 12 Gauge Steel, Concealed Hinge, 3-Point Latch, 2-Door, Freestanding Enclosure

Freestanding Enclosure; Type 2-Door; Height 90.06 Inch; Width 72.06 Inch; Depth 24.06 Inch; Material Steel; Material Specification 12 Gauge; Color ANSI 61 Gray; Finish Polyester Powder Coated; Door Type 2-Door Dual Access; Door Mounting Concealed Hinged, 3-Point Latch with Oil Tight Key-Locking Handle; Enclosure NEMA 12, IP55; Mounting Floor; Approval UL 508A, CUL, CSA C22.2; Lead-Free; RoHS Compliant; Number of Rack Units 45; Includes 2-Lifting Eye; Applicable Standard IEC 60529

MFG #: A907224FSDADG

EECO #: HOA907224FSDADG

Brand: Hoffman
UPC #: 783510388898
Attributes
Features
Documents
Product Information
Attributes
Color
ANSI 61 Gray
Finish
Polyester Powder Coated
UNSPSC
39121324
Approval
UL 508A, CUL, CSA C22.2
Material
Steel
Nema Rating
NEMA 12, IP55
Mounting
Floor
Material Specification
12 Gauge
Type
2-Door
Depth
24.06 Inch
Width
72.06 Inch
Height
90.06 Inch
Door Type
2-Door Dual Access
Door Mounting
Concealed Hinged, 3-Point Latch with Oil Tight Key-Locking Handle
Features
  • Seams Continuously Welded and Ground Smooth
  • Data Pocket is High-Impact Thermoplastic
  • Bonding Provision on Door
  • No Holes or Knockouts
  • Provision for Mounting Fluorescent Light
  • Internal Mounting Channels Welded Horizontally to Sides at Top, Bottom and Center
  • Optional Panels and Rack Mounting Angles Can be Mounted Anywhere Along Channels
  • Lead-Free
  • RoHS Compliant
HOFMANE01143_1_5
HOFMANINST00033
