86.12 x 112 x 14.12, Hoffman A86M3EG Freestanding Enclosure, NEMA 12/IP55, 12 Gauge Steel, Multi-Door

Short Description

86.12" x 112" x 14.12", NEMA 12, IP55, ANSI 61 Gray, Polyester Painted, 12 Gauge Steel, 3-Point Latch, Multi-Door, Freestanding Enclosure W/Padlocking Handle

Freestanding Enclosure; Type Multi-Door; Height 86.12 Inch; Width 112 Inch; Depth 14.12 Inch; Material Steel; Material Specification 12 Gauge; Color ANSI 61 Gray; Finish Polyester Painted; Door Mounting 3-Point Latch with Padlocking Handle, Concealed Hinge, Heavy Steel Back Stiffener; Enclosure NEMA 12, IP55; Approval UL 508A, CUL, CSA C22.2; RoHS Compliant

MFG #: A86M3EG

EECO #: HOA86M3EG

Brand: Hoffman
UPC #: 783510389093
Attributes
Features
Documents
Product Information
Attributes
Color
ANSI 61 Gray
Finish
Polyester Painted
UNSPSC
39121324
Approval
UL 508A, CUL, CSA C22.2
Material
Steel
Nema Rating
NEMA 12, IP55
Material Specification
12 Gauge
Type
Multi-Door
Depth
14.12 Inch
Width
112 Inch
Height
86.12 Inch
Door Mounting
3-Point Latch with Padlocking Handle, Concealed Hinge, Heavy Steel Back Stiffener
Features
  • Seams Continuously Welded and Ground Smooth
  • No Holes or Knockouts
  • Heavy Steel Back Stiffeners Maintain Flatness and Increase Rigidity
  • Heavy-Duty Lifting Eyes Anchored into Reinforced Top
  • Mechanical Interlock Standard on Each Enclosure with Right-Hand Door Serving as Master Door
  • Doors Can be Closed in any Order
  • Bonding Provision on Doors
  • Provisions for Mounting Fluorescent Lights
  • RoHS Compliant
HOFFMAE00007_112_113
HOFMANE01146_1_4
HOFMANINST00033
