12 x 24 x 8, Hoffman A122408LP Wall Mount Enclosure, NEMA 12/13/IP65, Mild Steel, 1-Door, HG Continuous Hinged w/Removable Pin

Short Description

12" x 24" x 8", NEMA 12/13, IP65, White Inside/ANSI 61 Gray Outside, 16 Gauge Mild Steel, Continuous Hinged, Padlockable Hasp and Staple Cover, 1-Door, Wall Mount Enclosure

Wall Mount Enclosure; Type 1-Door; Height 12 Inch; Width 24 Inch; Depth 8 Inch; Material Mild Steel; Material Specification 16 Gauge; Color White Inside/ANSI 61 Gray Outside (Body), ANSI 61 Gray Inside/Outside (Door); Cover Type Heavy Gauge Continuous Hinged with Removable Pin, Gasketed, Clamp, Padlockable Hasp and Staple; Back Panel A12P24, A12P24G; Enclosure NEMA 12/13, IP65; Mounting External Bracket, Wall; Approval UL 508A, CUL, CSA C22.2; RoHS Compliant; Number of Clamps 2; Includes Small Data Pocket; Applicable Standard IEC 60529

MFG #: A122408LP

EECO #: HOA122408LP

Brand: Hoffman
UPC #: 783510281304
Attributes
Features
Documents
Product Information
Attributes
Color
White Inside/ANSI 61 Gray Outside (Body), ANSI 61 Gray Inside/Outside (Door)
UNSPSC
39121324
Approval
UL 508A, CUL, CSA C22.2
Mounting
External Bracket, Wall
Material Specification
16 Gauge
Type
1-Door
Features
  • Seams Continuously Welded and Ground Smooth
  • External Wall Mounting Brackets for Easy Installation
  • Formed External Return Flanges Around All Sides of Enclosure Opening
  • Screw-down door clamps
  • Data Pocket is High Impact Thermoplastic
  • Bonding Provision on Door
  • Oil Resistant Gasket
  • RoHS Compliant
Qty Unit price
Ea
1 $537.00

Slqt
1 $537.00

Stpk
1 $537.00

Unit
1 $537.00
