12 x 12 x 6, Hoffman A1212CHNF Wall Mount Enclosure, NEMA 4/12/13/IP66, Steel, 1-Door, Continuous Hinged

Short Description

12" x 12" x 6", NEMA 4/12/13, IP66, ANSI 61 Gray Polyester Powder Coated, 14 Gauge Steel, Continuous Hinged Cover, 1-Door, Wall Mount Enclosure

Wall Mount Enclosure; Type 1-Door; Height 12 Inch; Width 12 Inch; Depth 6 Inch; Material Steel; Material Specification 14 Gauge; Color ANSI 61 Gray; Finish Polyester Powder Coated; Cover Type Continuous Hinged, Gasketed, Clamp; Back Panel A12P12, A12P12G; Enclosure NEMA 4/12/13, IP66; Mounting Bracket; Service Type Indoor/Outdoor; Approval UL 50/50E, CUL, CSA C22.2; RoHS Compliant; Applicable Standard IEC 60529

MFG #: A1212CHNF

EECO #: HOA1212CHNF

Brand: Hoffman
UPC #: 783510554804
Attributes
Features
Documents
Product Information
Attributes
Color
ANSI 61 Gray
Finish
Polyester Powder Coated
UNSPSC
39121324
Approval
UL 50/50E, CUL, CSA C22.2
Service Type
Indoor/Outdoor
Mounting
Bracket
Material Specification
14 Gauge
Type
1-Door
Features
  • Seams Continuously Welded and Ground Smooth
  • Stainless Steel Screw-Down Clamps on Three Sides of Door
  • Oil Resistant Gasket
  • Bonding Provision on Door
  • External Welded-On Mounting Brackets for Easy Installation
  • RoHS Compliant
Qty Unit price
Ea
1 $234.00

Slqt
1 $234.00

Stpk
1 $234.00

Unit
1 $234.00
