HARTING® 09 20 003 2711 Han A® Terminal Insert, 3 Positions, 18 to 14 AWG Wire, Female Screw Connection, Polycarbonate

Short Description

21 MM x 26.2 MM, 3-Contact, 230/250/400 V, 10 A, Polycarbonate, Screw Termination, Female, Industrial Connector Insert

HARTING® Terminal Insert, Series: Han A®, 3 Positions, 18 to 14 AWG Wire, Female Screw Connection, -40 to 125 deg C, Specifications: 10 A Rated, 4 kV Rated Impulse Voltage, Polycarbonate, Pebble Gray, 26.2 mm L Dimensions
MFG #: 09 20 003 2711

EECO #: HG09200032711

Brand: HARTING®
UPC #: 999999046628
Attributes
Features
Documents
Product Information
Attributes
Color
Pebble Gray
UNSPSC
39121400
Used On
Industrial Connector
Material
Polycarbonate
Wire Size
18 to 14
Current Rating
10 Amp
Connection Type
Female Screw
Temperature Rating
-40 to 125
Series
Han A®
Dimensions
26.2 mm L
Specifications
10 A Rated, 4 kV Rated Impulse Voltage
Number of Contacts
3
Features
  • V-0 flammability according to UL 94
  • = 500 mating cycles
  • = 1010 ohm insulation resistance
  • 600 V rated voltage according to UL
  • 3 deg pollution
  • 400 V rated voltage conductor-conductor
  • 230 V rated voltage conductor-ground
  • 0.75 to 1.5 sq-mm conductor cross section
  • Copper alloy material
  • RAL 7032 pebble grey material
  • 0.25 N-m tightening torque
  • 3A size
  • Silver plated contact
  • 2.5 - 5.5 mm stripping length
HARTIN_09_20_003_2711_CAD
HARTINE00049_01_3
HARTING_09_20_003_2711_Line_Drawing
