Print600 VAC/VDC, 30 A, Mersen EP 60308SJ Fuse Block, 3-Pole, Class J
600 VAC/VDC, 30 A, 14 to 2 AWG Aluminum/Copper, 3-Pole, Molded Glass Filled Polycarbonate, Box Lug Terminal, Spring Reinforced Clip, Class J, Standard, Fuse Block
Fuse Block; Type Standard; Material Molded Glass Filled Polycarbonate; Number of Poles 3; Fuse Type Class J; Fuse Voltage Rating 600 Volt AC/DC; Fuse Current Rating 30 Amp; Wire Size 14 to 2 AWG (Aluminum/Copper); Terminal Type Box Lug; Clip Type Spring Reinforced; Approval UL 512/4248, CSA Class 6225; RoHS Compliant; Overall Dimension 3.9 Inch Length x 3.62 Inch Width x 2.2 Inch Height; Short Circuit Current Rating 200 Kiloamp; Fuse Installation Method Clip-In; Clip Material Tin Plated Copper; Installation Mounting Type Screw or DIN Rail; Connector Torque Rating 35 Inch-Pound
EECO #: GF60308SJ
| Qty | Unit price |
|---|---|
| Ea | |
| 1 | $63.87 |
|
Slqt |
|
| 1 | $63.87 |
|
Stpk |
|
| 1 | $63.87 |
|
Unit |
|
| 1 | $63.87 |
