Littelfuse® SSAC® ARP42S Electro-Mechanical Alternating Relay, 10 A, 11 Pin, DPDT Contact, 120 VAC V Coil
Share Share Print Print
Littelfuse, Inc.

Littelfuse® SSAC® ARP42S Electro-Mechanical Alternating Relay, 10 A, 11 Pin, DPDT Contact, 120 VAC V Coil

Short Description

The ARP series is used in systems where equal run time for two motors is desirable. The selector switch allows selection of alternation of either load for continuous operation. LED's indicate the status of the output relay. This versatile series may be front panel mounted (BZ1 accessory required) or 35 mm DIN rail mounted with an accessory socket.

Littelfuse® SSAC® Alternating Relay, Electro-Mechanical, Series: ARP, 10 A, 50/60 Hz Frequency, 120 VAC Coil, DPDT Contact Form, 10 A Resistive at 120/240 VAC/28 VDC, 1/3 hp at 120/240 VAC Contact, 11 Pins, Plug-In Mounting, -20 to 60 deg F, 2.39 in W x 45.2 in D x 3.2 in H Dimensions

MFG #: ARP42S

EECO #: ETXARP42S

Brand: Littelfuse
UPC #: 079458991451
Attributes
Features
Documents
Product Information
Attributes
UNSPSC
39122331
Coil Voltage
120
Mounting Type
Plug-In
Contact Rating
10 A Resistive at 120/240 VAC/28 VDC, 1/3 hp at 120/240 VAC
Number of Pins
11
Frequency Rating
50/60
Temperature Rating
-20 to 60
Type
Electro-Mechanical
Series
ARP
Dimensions
2.39 in W x 45.2 in D x 3.2 in H
Amperage Rating
10
Features
  • Rotary switch allows user to lock internal relay to one specific load
  • -20 to 10% tolerance
  • 250 VAC max output voltage
  • 1500 Vrms input to output isolation voltage
  • 1 x 10^7 mechanical and 1 x 10^7 electrical life
  • Magnal 11-pin termination
  • Plug-in socket mounting
IDW_DOCUMENT_87dd69afcf469a948d9f79aafdb592f8b12dff1f4cf00bf9444a598c486e0f3c
Littelfuse_ARP42S_Catalog
Qty Unit price
Ea
1 $57.99
