EATON Z20N11E07CU Type EPZ General Purpose Encapsulated Transformer, 240 x 480 V Primary, 120/240 V Secondary, 7.5 kVA Power Rating, 50/60 Hz, 1 Phase
Share Share Print Print
Eaton

EATON Z20N11E07CU Type EPZ General Purpose Encapsulated Transformer, 240 x 480 V Primary, 120/240 V Secondary, 7.5 kVA Power Rating, 50/60 Hz, 1 Phase

Short Description

Type EPZ (1-phase) transformers are UL listed and suitable for installation in Class I, Div 2 Groups A, B, C and D locations and offer a solution for many petrochemical and other industrial facilities with atmospheres unsuitable for application of either liquid filled or general purpose dry-type transformers.

EATON Encapsulated Transformer, Type EPZ General Purpose, 240 x 480 V Primary, 120/240 V Secondary, 7.5 kVA Power, 50/60 Hz, 1 ph, 90A Connection, 178H Frame Circuit, 180 deg C Insulation, NEMA 3R Enclosure, 115 deg C, 9.89 in L x 10.38 in W x 12.82 in H
MFG #: Z20N11E07CU

EECO #: CHZ20N11E07CU

Brand: Eaton
UPC #: 786680233050
Attributes
Features
Documents
Product Information
Attributes
Phase
1
UNSPSC
39121027
Application
Commercial, Institutional Buildings and Structures
Circuit Type
178H Frame
Power Rating
7.5
Enclosure Type
NEMA 3R
Connection Type
90A
Frequency Rating
50/60
Temperature Rating
115
Type
Type EPZ General Purpose
Dimensions
9.89 in L x 10.38 in W x 12.82 in H
Primary Voltage
240 x 480
Secondary Voltage
120/240
Features
  • Encapsulated transformers are specifically excluded from the scope of US DOE energy efficiency requirements
  • Cores are grounded with a copper lead
  • Electrostatically shielded
  • Copper windings
