EATON RMQ-Titan® M22-KC02SMC10 Emergency Stop Non-Illuminated Self-Monitoring Contact Block, 22.5 mm, 2NC Contact, 6 A at 240 VAC, 3 A at 24 VDC Contact, Black
Share Share Print Print
Eaton

EATON RMQ-Titan® M22-KC02SMC10 Emergency Stop Non-Illuminated Self-Monitoring Contact Block, 22.5 mm, 2NC Contact, 6 A at 240 VAC, 3 A at 24 VDC Contact, Black

Short Description

This attractive, functional line of pushbuttons features a space-saving construction that enables fast assembly. The complete illuminated M22 line offers LED light units to ensure high-quality brightness and up to 100,000 hours of illumination. Because of the rugged design of these pushbuttons, most operators and contact blocks exceed five million mechanical operations.

EATON RMQ-Titan® Contact Block, Emergency Stop Non-Illuminated Self-Monitoring, Series: M22, 22.5 mm Size, 2NC Contact Configuration, 6 A at 240 VAC, 3 A at 24 VDC Contact, Pushbutton Operator, NEMA 4X/13 NEMA Rating, IP20/IP65 Enclosure, Screw Terminal, Base Mounting, Black, 1.46 in L x 1.18 in W x 1.03 in H Dimensions
MFG #: M22-KC02SMC10

EECO #: CHM22KC02SMC10

Brand: Eaton
UPC #: 786685476490
Attributes
Features
Documents
Product Information
Attributes
Color
Black
UNSPSC
39121410
Mounting Type
Base
Operator Type
Pushbutton
Terminal Type
Screw
Contact Rating
6 A at 240 VAC, 3 A at 24 VDC
Enclosure Type
IP20/IP65
Contact Configuration
2NC
Size
22.5
Type
Emergency Stop Non-Illuminated Self-Monitoring
Series
M22
Warranty
1 year
Dimensions
1.46 in L x 1.18 in W x 1.03 in H
Features
  • 6 A at 115/220/230/240 VAC, 4 A at 380/400/415 VAC, 2 A at 500 VAC, 3 A at 24 VDC, 1.7 A at 42 VDC, 1.2 A at 60 VDC, 0.8 A at 110 VDC, 0.3 A at 220 VDC
  • NC contact blocks are positively driven
