EATON CSDS4A4CMR22.3 Global Plus 4-Wire Standard Single End Connector Cable, M12x1 4-Pin Micro-Style Straight Male Connector, 3 m L Cable
Share Share Print Print
Eaton

EATON CSDS4A4CMR22.3 Global Plus 4-Wire Standard Single End Connector Cable, M12x1 4-Pin Micro-Style Straight Male Connector, 3 m L Cable

Short Description

Finish your sensor installation with high quality connector cables from EATON electrical sector. Our Global Plus line is designed to give you everything you want without paying extra for the features you don't want. It includes a wide variety of single and double connector cables. Custom lengths are available upon request from the factory.

EATON Connector Cable, 4-Wire Standard Single End, Series: Global Plus, 4-Pin Micro-Style Straight Male Connector, M12x1 Connector, Die Cast Zinc Connector, Copper/Stranded Cable, 3 m Cable Length, PVC Cable, 320 VDC, 4 A, Black/Blue/Brown/White Wire Pin
MFG #: CSDS4A4CMR22.3

EECO #: CHCSDS4A4CMR22.3

Brand: Eaton
UPC #: 786685199160
Attributes
Features
Documents
Product Information
Attributes
UNSPSC
41111926
Cable Type
Copper/Stranded
Application
Photoelectric Sensor Applications
Cable Length
3
Connector Type
4-Pin Micro-Style Straight Male
Voltage Rating
320
Connector Material
Die Cast Zinc
Type
4-Wire Standard Single End
Series
Global Plus
Warranty
1 year
Amperage Rating
4
Features
  • Type: 4-Wire Standard Single End Connector Cable
  • Series: Global Plus
  • Connector Style: 4-Pin Micro-Style Straight Male Connector
  • Connector Specification: M12x1
  • Connector Material: Die Cast Zinc
  • Cable Material: Copper/Stranded
  • Cable Length: 3 meters
  • Cable Insulation: PVC
  • Voltage Rating: 320 VDC
  • Current Rating: 4 A
  • Wire Colors: Black, Blue, Brown, White
