EATON C25DND330T D-Frame Non-Reversing Definite Purpose Control Contactor With Metal Mounting Plate, 24 VAC at 50/60 Hz V Coil, 30 A, 3 Poles

Short Description

Definite purpose starters are electrically operated switching devices specifically designed for the heating, ventilation, air conditioning and refrigeration (HVAC) industry. They are controlled by automatic thermostat control or manual pushbutton interfaces.

EATON Definite Purpose Control Contactor, D-Frame Non-Reversing, 24 VAC at 50/60 Hz Coil, 30 A Maximum Load Current, 3 Pole, Double Break Contact, Quick-Connect (Side by Side) Connection, Pressure Plate/Screw Terminal, Open Enclosure, 300000 Cycles Operating Cycles, 150 deg F Operating, Surface Mounting, 3.35 in L x 2.4 in W x 3.75 in H Dimensions

MFG #: C25DND330T

EECO #: CHC25DND330T

Brand: Eaton
UPC #: 782116300624
Attributes
Features
Documents
Product Information
Attributes
UNSPSC
39121529
Approval
UL, CSA, CE
Application
Heating, Ventilation, Air Conditioning, Refrigeration (HVACR), Motor and Power Control Equipment
Coil Voltage
24 VAC at 50/60 Hz
Contact Type
Double Break
Mounting Type
Surface
Terminal Type
Pressure Plate/Screw
Enclosure Type
Open
Connection Type
Quick-Connect (Side by Side)
Number Of Poles
3
Enclosure
Open
Power Rating/Voltage
5 HP at 230 Volt 1-Phase, 10 HP at 230 Volt 3-Phase
Construction Standard
IEC 60947-4-1, EN 60947-4-1
Operating Temperature
150
Size
Frame D
Type
D-Frame Non-Reversing
Warranty
1 year
Dimensions
3.35 in L x 2.4 in W x 3.75 in H
Inductive Ampere
30 Amp
Resistive Ampere
40 Amp
Maximum Load Current
30
Features
  • The universal mounting plate eliminates changing hole patterns when replacing competitive devices
  • Variety of terminal styles allows product to meet all specific application needs
  • Snap-on accessories require no tools for hassle-free installation
  • Quick coil changing ability allows for easy maintenance
  • Non-position sensitive mounting allows for fast, convenient setup
  • Shrouded or fingerproof terminals to reduce possibility of electrical shock
  • 15 to 50 A frame
