EATON 3BR1224L125R 3-Phase Metallic Main Lug Loadcenter, 120/208Y/240 VAC, 125 A, 24 Poles, 10 kA Interrupt

Short Description

Specially designed for easy installation, EATON BR 1 in loadcenters house the branch circuit breakers and the wiring required to distribute power to individual circuits. They serve as main breaker for service entrances or as main lug when adding circuits to existing service. The main breaker protects the main entire panel and can be used as a service disconnect. The branch breakers protect the wires leading to individual electrical loads such as fixtures and outlets.

EATON Main Lug Loadcenter, 3-Phase Metallic, 120/208Y/240 VAC, 125 A, 24 Pole, 10 kA Interrupt, 24 Circuits, BR Breaker, 4-Wire Wiring Configuration, 12 Spaces, 6 to 2/0 AWG Wire, Surface Mount, NEMA 3R, NEMA C1R Enclosure Box, 5.19 in L x 14.31 in W x 21 in H

MFG #: 3BR1224L125R

EECO #: CH3BR1224L125R

Brand: Eaton
UPC #: 786676441452
Attributes
Features
Documents
Product Information
Attributes
UNSPSC
39121101
Approval
UL
Wire Size
6 to 2/0
Application
Power Distribution and Commercial Applications
Bus Material
Tin Plated Aluminum
Neutral Type
Insulated/Bondable
Feed Location
Top/Bottom
Mounting Type
Surface
Current Rating
125 Amp
Enclosure Type
NEMA 3R
Voltage Rating
120/208Y/240
Breaker Mounting
Plug-On
Interrupting Rating
10 Kiloamp
Size
14.31 Inch Width x 5.19 Inch Depth x 21 Inch Height
Type
3-Phase Metallic
Includes
BREQS125 Hold Down Screw and Cover
Warranty
10 years
Dimensions
5.19 in L x 14.31 in W x 21 in H
Breaker Type
BR
Main Wire Size
6 to 2/0 AWG (Copper/Aluminum)
Amperage Rating
125
Main Breaker Type
BR
Number of Circuits
24
Circuit Configuration
3-Phase 4-Wire
Maximum Number of Spaces
(12) 1 Inch
Enclosure Size Designation
C1R
Maximum Number of Circuits
24
Features
  • Flexible neutral design
  • Tangential main knockout
  • Single key hole mounting
  • Factory pre-attached neutral bonding strap
  • For use with type BR 1 in breakers
  • Outdoor rainproof enclosure
  • Copper aluminum wire at 60 to 75 deg C for main lugs
  • Standard tin plated aluminum bus for excellent conductivity and corrosion-resistance
  • No feed-through lugs
