EATON 10250T57 Heavy Duty Special Purpose Contact Block, 30.5 mm, 1LONC-1ECNO Contact, 10 A at 600 VAC, 5 A at 250 VDC Contact, Silver Contact, Momentary Action, Black

Short Description

Eaton's 10250T line of 30.5 mm pushbuttons features a heavy duty zinc Die-Cast construction. Reliability nibs improve contact reliability even under dry circuit and fine dust conditions. In addition, drainage holes prevent the buildup of liquid inside the operator, which can prevent operation in freezing environments.

EATON Contact Block, Heavy Duty Special Purpose, Series: 10250T, 30.5 mm Size, 1LONC-1ECNO Contact Configuration, 10 A at 600 VAC, 5 A at 250 VDC Contact, Silver Contact, Momentary Action, Thermoplastic Block, Pushbutton Operator, NEMA 3/3R/4/4X/12/13 NEMA Rating, IP65 Enclosure, Pressure Terminal, 4-Stack Mounting, Die-Cast Zinc, Black, 1.9 in L x 1.3 in W x 2.2 in H Dimensions
MFG #: 10250T57

EECO #: CH10250T57

Brand: Eaton
UPC #: 782113225449
Attributes
Features
Documents
Product Information
Attributes
Color
Black
UNSPSC
39122221
Material
Die-Cast Zinc
Application
For automation and logic control equipment applications
Mounting Type
4-Stack
Operator Type
Pushbutton
Terminal Type
Pressure
Contact Rating
10 A at 600 VAC, 5 A at 250 VDC
Enclosure Type
IP65
Contact Configuration
1LONC-1ECNO
Size
30.5
Type
Heavy Duty Special Purpose
Series
10250T
Warranty
1 year
Dimensions
1.9 in L x 1.3 in W x 2.2 in H
Contact Material
Silver
Features
  • Stack up to 4-blocks unless otherwise noted
  • One early closing NO and one standard NO
  • Not for use on 4-position selector switch, push-pulls or 2-position joystick or padlock attachments
