Eaton

EATON 1008950CH 1-Position 4-Wire Lever Bypass Triplex Meter Socket, 600 VAC, 320 A, 3 Phase

Short Description

EATON line of single position, self-contained meter sockets house the utilities electrical watt hour meters in residential and commercial buildings. Choose from the widest range of utility approved sockets in the industry, including 100 to 320 A units and designs such as ring less, bypass, and more.

EATON Meter Socket, 1-Position 4-Wire Lever Bypass Triplex, 600 VAC, 320 A, 3 ph, Bottom/Overhead/Top/Underground Feed, 7 Jaws, 14 to 2 AWG Wire, Open Hub, 5 x 5 in Hub, Ringless Cover, 6.5 in L x 20 in W x 39.88 in H Dimensions
MFG #: 1008950CH

EECO #: CH1008950CH

Brand: Eaton
UPC #: 782116168675
Attributes
Features
Documents
Product Information
Attributes
Phase
3
UNSPSC
39121102
Hub Size
5 x 5
Wire Size
14 to 2
Application
Power Distribution, Commercial, Residential Buildings and Facilities Applications
Voltage Rating
600
Type
1-Position 4-Wire Lever Bypass Triplex
Hub Type
Open
Warranty
1 year
Cover Type
Ringless
Dimensions
6.5 in L x 20 in W x 39.88 in H
Amperage Rating
320
Features
  • Anti-inver clip factory installed
  • 3/8 in stud connection
