EATON 1000THFSR432 3-Phase Filtered Heavy Duty Low Voltage Round Switched Detuned Filter, 480 VAC, 1203 A, 60 Hz, Floor Mount, Steel

Short Description

AutoVAR filters are an automatically switched, free standing Power Factor Correction capable device designed for low voltage applications in installations requiring precise maintenance of target power factor in a very small footprint for operation (by incorporating de-tuning reactors) in electrical harmonic environments.

EATON Detuned Filter, 3-Phase Filtered Heavy Duty Low Voltage Round Switched, 480 VAC, 1203 A, 60 Hz Frequency, Rugged Copper Busbar Connection, Mechanical Wire Lug Terminal, Floor Mounting, -20 to 46 deg C Operating, Steel, Gray, 25 in L x 170 in W x 78 in H Dimensions
MFG #: 1000THFSR432

EECO #: CH1000THFSR432

Brand: Eaton
UPC #: 786680167812
Attributes
Features
Documents
Product Information
Attributes
Color
Gray
UNSPSC
39121014
Material
Steel
Application
For service entrance or substation power factor correction and main low voltage switchgear
Mounting Type
Floor
Terminal Type
Mechanical Wire Lug
Voltage Rating
480
Connection Type
Rugged Copper Busbar
Frequency Rating
60
Operating Temperature
-20 to 46
Type
3-Phase Filtered Heavy Duty Low Voltage Round Switched
Includes
Mechanical Wire Lugs
Warranty
1 year
Dimensions
25 in L x 170 in W x 78 in H
Amperage Rating
1203
Features
  • Removable lift bolts standard cabinet
  • Power line interconnect
  • Modular tray design
  • 200000 A interrupting capacity provided on all 3-phase of each stage. Blade type fuses mounted on insulator stand-offs
  • Cleared fuse indicating lights
  • Push to test allows testing of door mounted LED cleared fuse indicating lights
  • Auto locate
  • Door interlock
  • Exhaust fans
  • Ease of expansion
  • Ease of replacement
  • Thermal sensing
