EATON WLRS2 WLRS Single Spring Door Cover, 1-1/2 in Dia, 2.91 in L x 1.13 in W x 4.44 in D, (1) Receptacle Cover, Copper-Free Aluminum

NOTICE: This item has been flagged as discontinued. Limited stock may be available. Please note that this item is subject to removal from your order if it is unfulfillable.
Short Description

Crouse-Hinds® series WLRS, WLRD and WLGF wiring device covers are designed to meet nec code requirements for wet and damp locations. They are suitable for use in industrial, commercial and residential areas as a general purpose utility receptacle cover or wherever portable equipment is required. The covers mount to Crouse-Hinds® series FS and FD single gang or multi-gang boxes with individual cover openings.

EATON, WLRS2, Spring Door Cover, Single, Series: WLRS, 1 Outlets, 1 Gangs, 1-1/2 in Diameter, 2.91 in Length, 1.13 in Width, 4.44 in Depth, Rectangle Shape, (1) Receptacle Cover, -50 to 260 deg F, Vertical Mounting, Threaded Mounting, Copper-Free Aluminum, Epoxy Painted, Gray
MFG #: WLRS2

EECO #: CBWLRS2

Brand: Eaton
UPC #: 782274128047
Discontinued
Attributes
Features
Documents
Product Information
Attributes
Color
Gray
Shape
Rectangle
Finish
Epoxy Painted
Length
2.91
UNSPSC
39121304
Approval
UL 514A
Material
Copper-Free Aluminum
Application
Ordinary/Non-Hazardous, Wet Location, Industrial Facilities, Factories and Standard On-Off Operation Applications
Mounting Type
Threaded
Number of Gangs
1
Mounting
Box, Screw
Mounting Position
Vertical
Number of Outlets
1.0000
Temperature Rating
-50 to 260
Mounting Orientation
Vertical
Size
2.91 Inch Width x 1.13 Inch Depth x 4.44 Inch Height
Type
Single
Depth
4.44
Width
1.13
Series
WLRS
Diameter
1-1/2
Includes
Gasket
Lid Type
Single Lid
Warranty
12 months
Cover Type
(1) Receptacle
Device Type
(1) Single Receptacle
Features
  • Self-closing spring door assures protection of wiring device at all times, in wet and damp locations
  • One piece EPDM gasket provides environmental protection of wiring device at all times
  • EPDM gasketing material offers excellent resistance to ozone, weather and temperature extremes of -50 to 260 deg f
  • Die cast copper-free aluminum construction with aluminum lacquer finish provides maximum corrosion-resistance
  • Positive ground path ensured for all exposed metal parts
  • NEMA configuration receptacle interiors - comply with NEMA standards WD-1 and WD-5
  • Grounded through an extra contact in all types except 3 ph applications, self-grounded in duplex variety
  • Back and side wired
  • Offered in single and duplex configurations for use with standard plugs
  • For nema configuration round receptacles
  • 1-piece EPDM gasket provides environmental protection of wiring device at all times
COOPRCE01320_37_38
COOPRCINST00342
IDW_DOCUMENT_e2591020677e3f4a06dfa44770294e5b59dc7819413ebeaa1bdb1ce89a7cea8b
IDW_DOCUMENT_64617abfacaf177473dd7b2e1d54eb1a14394a2c35c08a929269d06df74469f2
IDW_DOCUMENT_ddf7d3840b7e96009a33878876d75d70bf9e6407931b495b08ff9668ddb00b2c
WLRS2_Specification_Sheet
WLRS_L5_15_Catalog
WLRS_L5_15_Installation_Manual
Qty Unit price
Ea
1 $68.30

Slqt
1 $68.30

Stpk
1 $341.50

Unit
1 $68.30
