EATON Crouse-Hinds Condulet® LL35 Type LL Conduit Outlet Body, 1 in Hub, 5 Form, 12.2 cu-in Capacity, Die Cast Copper-Free Aluminum, Epoxy Powder Coated
EATON Crouse-Hinds Condulet® LL35 Type LL Conduit Outlet Body, 1 in Hub, 5 Form, 12.2 cu-in Capacity, Die Cast Copper-Free Aluminum, Epoxy Powder Coated
EATON Crouse-Hinds Condulet® LL35 Type LL Conduit Outlet Body, 1 in Hub, 5 Form, 12.2 cu-in Capacity, Die Cast Copper-Free Aluminum, Epoxy Powder Coated
EATON Crouse-Hinds Condulet® LL35 Type LL Conduit Outlet Body, 1 in Hub, 5 Form, 12.2 cu-in Capacity, Die Cast Copper-Free Aluminum, Epoxy Powder Coated
Share Share Print Print
Eaton

EATON Crouse-Hinds Condulet® LL35 Type LL Conduit Outlet Body, 1 in Hub, 5 Form, 12.2 cu-in Capacity, Die Cast Copper-Free Aluminum, Epoxy Powder Coated

NOTICE: This item has been flagged as discontinued. Limited stock may be available. Please note that this item is subject to removal from your order if it is unfulfillable.
Short Description

Eaton Crouse-Hinds Division Series 5 die cast copper-free aluminum conduit bodies, covers and gaskets are available for use with rigid or EMT conduit (with set screw). Conduit bodies are available in trade sizes 1/2 to 4 in, in the most popular conduit body shapes (C, LB, LL, LR, T) and 1/2 to 2 in TB and X shapes. The Series 5 family is available as components or pre-packaged in various configurations as a SnapPack assembly. In addition, Series 5 is completely interchangeable with other manufacturers.

EATON Crouse-Hinds Condulet® Conduit Outlet Body, Type LL, 1 in Hub, 2 Hubs, 12.2 cu-in Capacity, 5, NEMA 4 Enclosure, Threaded/Set Screw, Surface Mount, Die Cast Copper-Free Aluminum, Epoxy Powder Coated, Gray, 5.94 in L x 2.68 in W x 1.9 in H

MFG #: LL35

EECO #: CBLL35

Brand: Crouse-Hinds
UPC #: 784564140234
Discontinued
Attributes
Features
Documents
Product Information
Attributes
Color
Gray
Finish
Epoxy Powder Coated
UNSPSC
39131708
Used On
IMC/Rigid Conduit
Approval
UL, CUL
Hub Size
1
Material
Die Cast Copper-Free Aluminum
Application
For rigid/IMC/EMT conduit, act as pull outlets for conductors being installed, provide openings for making splices and taps in conductors and commercial, institutional buildings and structures
Hub Location
90 Degree
Installation
Set Screw, Threaded
Mounting Type
Surface
Number of Hubs
2
Connection Type
Threaded/Set Screw
Enclosure
NEMA 4
Size
5.94 Inch Length x1.9 Inch Width x 2.68 Inch Height
Type
Type LL
Style
LL
Series
5 Series
Capacity
12.2
Includes
Hubs and Tri Head Set Screws
Warranty
Limited
Cover Type
Natural Finished Aluminum, Screw-On
Dimensions
5.94 in L x 2.68 in W x 1.9 in H
Features
  • Die cast copper-free aluminum construction is lightweight and corrosion-resistant for long, reliable service
  • Epoxy powder coated finish provides additional corrosion resistance and an aesthetically pleasing appearance
Eaton_CrouseHinds_00028_37_39_CAT
IDW_DOCUMENT_e2591020677e3f4a06dfa44770294e5b59dc7819413ebeaa1bdb1ce89a7cea8b
Qty Unit price
C
1 $1,557.99

Ea
1 $15.5799

Slqt
1 $15.58

Stpk
1 $77.90

Unit
1 $15.58
