Eaton

Bussmann TB100-10 10-Pole Double Row Terminal Block, 300 V, 30 A, 22 to 14 AWG Wire, Black

Short Description

Efficiently connect and organize your wiring with the Bussmann TB100-10 10-Pole Double Row Terminal Block. Designed for durability and reliability, this terminal block accommodates 22 to 14 AWG wire and supports up to 30 A at 300 V. Perfect for your electrical projects! Enhanced by AI

Bussmann Terminal Block, 10-Pole Double Row, Series: TB100, 300 V, 30 A, 22 to 14 AWG Wire, 3/8 in Center Spacing, #6-32 Screw, 9 in-lb, Panel Mount, Phillips® Slot Screw, -40 to 130 deg C, Thermoplastic, Black, 4.4 in L x 0.88 in W x 0.41 in H

MFG #: TB100-10

EECO #: BUTB10010

Brand: Bussmann
UPC #: 051712810722
Attributes
Features
Documents
Product Information
Attributes
Color
Black
UNSPSC
39121410
Material
Thermoplastic
Wire Size
22 to 14
Application
Stationary Machine Equipment in Factory - Robotics
Mounting Type
Panel
Torque Rating
9
Voltage Rating
300
Connection Type
Phillips® Slot Screw
Temperature Rating
-40 to 130
Type
10-Pole Double Row
Series
TB100
Dimensions
4.4 in L x 0.88 in W x 0.41 in H
Screw Size
#6-32
Center Spacing
3/8
Amperage Rating
30
Features
  • Model: Bussmann TB100-10
  • Type: 10-Pole Double Row Terminal Block
  • Voltage Rating: 300 V
  • Current Rating: 30 A
  • Wire Gauge Compatibility: 22 to 14 AWG
  • Center Spacing: 3/8 in
  • Screw Type: #6-32 Screw with Phillips® Slot
  • Tightening Torque: 9 in-lb
  • Mounting Type: Panel Mount
  • Operating Temperature Range: -40 to 130 °C
  • Material: Thermoplastic
  • Color: Black
  • Dimensions: 4.4 in L x 0.88 in W x 0.41 in H

Enhanced by AI
