Bussmann NFT3-WH 2-Circuit Feed-Through Terminal Block, 600 VAC, 40 A, 22 to 8 AWG Wire, 3 Poles, C-Rail Mount
Bussmann NFT3-WH 2-Circuit Feed-Through Terminal Block, 600 VAC, 40 A, 22 to 8 AWG Wire, 3 Poles, C-Rail Mount
Bussmann NFT3-WH 2-Circuit Feed-Through Terminal Block, 600 VAC, 40 A, 22 to 8 AWG Wire, 3 Poles, C-Rail Mount
Bussmann NFT3-WH 2-Circuit Feed-Through Terminal Block, 600 VAC, 40 A, 22 to 8 AWG Wire, 3 Poles, C-Rail Mount
Share Share Print Print
Eaton

Bussmann NFT3-WH 2-Circuit Feed-Through Terminal Block, 600 VAC, 40 A, 22 to 8 AWG Wire, 3 Poles, C-Rail Mount

Short Description

Enhance your electrical connections with the Bussmann NFT3-WH 2-Circuit Feed-Through Terminal Block. Designed for reliability and efficiency, this terminal block supports up to 600 VAC and 40 A, accommodating wire sizes from 22 to 8 AWG. Its durable thermoplastic construction and convenient C-Rail mounting make it an essential component for any electrical setup.Enhanced by AI

Bussmann Terminal Block, 2-Circuit Feed-Through, 600 VAC, 40 A, 3 Pole, 22 to 8 AWG Wire, 9.91 mm Spacing, 18 in-lb Torque, C-Rail Mounting, #8-32 TPI Screw Connection, 105 deg C, Thermoplastic, White, 1.18 in L x 1.29 in W x 1.23 in H Dimensions

MFG #: NFT3-WH

EECO #: BUNFT3WH

Brand: Bussmann
UPC #: 051712588119
Attributes
Features
Documents
Product Information
Attributes
Color
White
UNSPSC
39121410
Material
Thermoplastic
Wire Size
22 to 8
Application
Electrical Assemblies, Panels and EOEM and Control Panels for Machines Applications
Mounting Type
C-Rail
Terminal Type
Screw
Torque Rating
18
Voltage Rating
600
Connection Type
#8-32 TPI Screw
Temperature Rating
105
Type
2-Circuit Feed-Through
Series
NFT3
Spacing
9.91
Dimensions
1.18 in L x 1.29 in W x 1.23 in H
Amperage Rating
40
Features
  • NFT3 C-rail terminal blocks provide a low profile, compact three poles footprint solution for various wire connection applications
  • The NFT3 features easy snap-on installation and accessories including jumpers and marking strips
  • 28 circuits per foot
  • JN3, 2 circuits jumper
NFT3_WH_Specification_Sheet
Bussmann_NFT3_WH_Specification_Sheet_CA
Bussmann_NFT3_WH_User_Manual_CA
