Bussmann NDN1-WH Feed-Through Terminal Block, 600 V, 90 A, 18 to 2 AWG Copper Wire, 1 Pole, DIN Rail/C-Rail/Surface Mount

Short Description

600 V, 90 A, 18 to 2 AWG, 1/4"-28 TPI Screw, 1-Circuit, White, Standard, Modular Terminal Block

Bussmann Terminal Block, Feed-Through, Series: NDN, 600 V, 90 A, 1 Pole, 18 to 2 AWG Copper Wire, Screw Terminal, 0.635 in Spacing, 32 in-lb, DIN Rail/C-Rail/Surface Mount, #1/4-28 Screw, 105 deg C, Thermoplastic, White, 0.59 in W x 1.71 in D x 1.43 in H

MFG #: NDN1-WH

EECO #: BUNDN1WH

Brand: Bussmann
UPC #: 051712590129
Attributes
Features
Documents
Product Information
Attributes
Color
White
UNSPSC
39121410
Approval
UL, CSA, CE
Material
Thermoplastic
Wire Size
18 to 2 AWG Copper
Application
Stationary Machine Equipment in Factory - Robotics
Mounting Type
DIN Rail/C-Rail/Surface
Terminal Type
Screw
Torque Rating
32
Current Rating
90 Amp
Voltage Rating
600
Connection Type
#1/4-28 Screw
Mounting
Rail
Temperature Rating
105
Type
Feed-Through
Series
NDN
Spacing
0.635
Includes
MT12-1-2 Marking Tape, NDNA Series 35mm DIN, DRL35MMLO 35mm DIN, DRL35MMHI 35mm DIN, NFTA Series C-Rail, NRA Series Low-Profile C-Rail Mounting Rails and NDN1A-WH White Modular Option
Dimensions
0.59 in W x 1.71 in D x 1.43 in H
Amperage Rating
90
Number of Circuits
1
Features
  • Easily snaps onto the mounting rail for a quick, simple, low-cost solution
  • Made of thermoplastic insulation, steel screw with zinc plated
  • 18 circuit per foot
