Eaton

Bussmann Limitron™ KLM-25 Fast Acting Low Voltage Midget Supplemental Fuse, 25 A, 600 VAC/VDC, 100000 A AC/50000 A DC Interrupt, Class: Supplemental, Cartridge Body

Short Description

600 VAC/VDC, 25 A, Ferrule Terminal, Fast Acting, Midget Fuse

Bussmann Limitron™ Fuse, Fast Acting Low Voltage Midget Supplemental, Series: KLM, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 25 A, 600 VAC/VDC, 100000 A AC/50000 A DC Interrupt, Class: Supplemental, 4 hr, 1 hr Response, Ferrule Terminal, Holder Mount, Cartridge Body Type, Single Element, Melamine, Black, 13/32 in Dia x 1-1/2 in L Body Size

MFG #: KLM-25

EECO #: BUKLM25

Brand: Bussmann
UPC #: 051712695251
Attributes
Features
Documents
Product Information
Attributes
Class
Supplemental
Color
Black
UNSPSC
39121609
Approval
UL 248-14, CSA C22.2, CE
Material
Melamine
Application
DC Control Circuits Requiring Fast Acting Fuses and PV Systems Up to 600 VDC, Safety and Security Systems
Mounting Type
Holder
Response Time
4 hr, 1 hr
Terminal Type
Ferrule
Current Rating
25 Amp
Voltage Rating
600
Characteristics
Fast Acting
Interrupting Rating
100 Kiloamp at 600 Volt AC, 50 Kiloamp at 600 Volt DC
Type
Fast Acting Low Voltage Midget Supplemental
Series
KLM
Diameter
13/32 Inch
Amperage Rating
25
Features
  • Color coded for 600 VAC/VDC voltage rating
  • A full range DC supplemental fuse
  • Melamine tube construction
  • Nickel plated brass end caps
  • 100 kA at 600 VAC, 50 kA at 600 VDC interrupt rating
  • 4 hr minimum at 100% of ampere rating, AC opens within 1 hr at 135% of amperage rating response time
COBUSSE01877_1_2
COBUSSE02627_3_6
EATCORE56432_1
Bussmann_KTS_R_75_Catalog
Qty Unit price
Ea
1 $20.58

Slqt
1 $20.58

Stpk
1 $205.80

Unit
1 $20.58
